Help CenterPE Serise Jaw Crusher for the First Time Crusher
Related Products
-
China Leading Jaw Crusher for Stone Breaking PlantUS$ 2,000 - 180,000MOQ: 1 Set -
Professional Manufacturer of Jaw Crusher for Various OresUS$ 2,000 - 180,000MOQ: 1 Set
-
High Capacity Jaw Crusher for Stone/Cement/Quarzsand With Quality CertificationUS$ 2,000 - 180,000MOQ: 1 Set
-
Highway Stone Crushing Equipment Jaw CrusherUS$ 2,000 - 180,000MOQ: 1 Set
-
Simple Structure Jaw Crusher With High Crushing RatioUS$ 2,000 - 300,000MOQ: 1 Set
Jaw Crusher used in mine prodcution line
Shanghai Dingbo Heavy Industry Machinery Co.,Ltd
Shanghai Dingbo Machinery Company has independent import-export right with a special international market department to deal with exporting affair. We have a professional after-sale service faculty to provide considerate and all-around-way service for the customers. Our products have taken up a considerable place in the world market. They have been exported to America, Italy, Turkey, Australia, Singapore, Indonesia, Vietnam, Iran, India, Chile, Venezuela, Libya, Ethiopia, United Arab Emirates, Kazakstan, Kyrgyzstan and receive high popularity.
Dingbo Machinery Jaw Crusher PE Series:
Jaw crusher is one of the most popular stone-crushing equipments in the world. It is ideally suitable for primary and secondary crushing processing machine selection. The highest anti-pressure strength of crushed material is 320MPA.
Based on many years' experience and technology development, Dingbo jaw crusher series are of 8 different types, which can meet most of the crushing requirements in primary and secondary crushing. Flexible discharge opening setting of jaw crusher allows perfect match with relative equipments. Dingbo jaw crushing machine is easy to install, operate and maintain. As each feedback, our experts will make continuous improvements on our products to meet customers' different needs. Primary Jaw Crusher is widely used in fields of mining, metallurgy, construction, smelting, hydropower and chemical industries etc.
Dingbo Machinery Jaw Crusher Struction:
A. Jaw Stock : Heavy duty cast Iron to hold the Swinging Jaw.
B. Swinging Jaw: Made of manganese Steel. They are replaceable and can be used both ways.
C. Cheek Plates: Are for holding in fixed jaw and they also protect the body.
D. Fixed Jaw: Are also made of manganese steel.
E. Tie Bar: For holding Jaw stock.
F. Toggle plates: To impart rolling motion to the Jaw Stock.
G. Fly Wheel: Made of heavy duty cast Iron to give momentum to crusher.
H. Bearing: Double row self aligning roller/Ball bearing fitted in Jaw stocks & main shaft in dust proof housings.
I. Control Lever: To adjust the opning of Jaws.
Dingbo Machinery Jaw Crusher Applied:
Jaw Crusher has been widely applied in mining, metallurgical, construction, road and railway building, water conservancy and chemistry etc. Jaw crusher can be as carborundum crusher, zircon crusher, gold ore crusher, quartz crusher, granite crusher, barite crusher, marble crusher, limestone crusher, kaolin crusher, talc crusher, coal crusher, gypsum crusher, blast furnace slag crusher, porcelain crusher, glass crusher, ballast crusher,etc.
Features of the Dingbo Machinery Jaw Crusher:
1. Durable advanced movable jaw:the material of Movable jaw is steel-casting with high quality and long time.
2. The bearing block is also with steel-casting material.
3. Jaw crusher/ Stone Crusher/Rock Crusher is with high crushing ratio.
4. Reasonable price, reliable performance.
5. Using new technology toothed plate, which improves the efficiency length of jaw plate and the capacity.
6. Modular design. you can just change the jaw plate if there is something wrong with it. etc.
Dingbo Machinery With Siemens Motor:
Factory:
Model:
Model |
Feeding Opening Size (mm) |
Max Feeding Size (mm) |
Adjustment Range of Discharge Openin (mm) |
Capacity (t/h) |
Electric Motor(kw) |
Overall Dimension(mm) |
Weight (t) |
|||
PE250×400 |
400×250 |
210 |
20-80 |
5-20 |
15 |
1450×1315×1296 |
2.8 |
|||
PE400×600 |
600×400 |
350 |
40-100 |
15-65 |
30 |
1700×1732×1653 |
6.2 |
|||
PE500×750 |
750×500 |
425 |
50-100 |
45-110 |
55 |
2035×1921×2000 |
11 |
|||
PE600×900 |
900×600 |
500 |
65-140 |
90-180 |
55-75 |
2290×2206×2370 |
16 |
|||
PE750×1060 |
1060×750 |
630 |
80-160 |
110-320 |
110 |
2655×2302×3110 |
29 |
|||
PE900×1200 |
900×1200 |
750 |
220-500 |
200-400 |
132 |
3380×2870×3330 |
54.5 |
|||
PE1000×1200 |
1200×1000 |
850 |
195-260 |
220-450 |
160 |
3480×3876×3330 |
58 |
|||
PE1200×1500 |
1500×1200 |
1020 |
150-300 |
400-800 |
180-220 |
4200×3750×3820 |
100.9 |
|||
