Help CenterMini Co2 Laser Cutter Machine for Acrylic,rubber,wood,plastic and Nonmetal Materials
Related Products
-
500*300mm up and Down Table Cheapest Low Price Co2 Desktop Mini Laser Engraver 40w Mini Laser Engraving Machine for Stamps Supplier's ChoiceUS$ 2,000 - 9,999MOQ: 1 Set -
Smart Mini Laser Engraving Machine 60w-150w Laser Wood Cutting Machine PriceUS$ 2,000 - 9,999MOQ: 1 Set
-
Desktop Laser GraverUS$ 2,000 - 9,999MOQ: 1 Set
-
Mini Crafts Laser Engraving Machine 60w-100w Laser Wood Cutting Machine PriceUS$ 2,000 - 9,999MOQ: 1 Set
-
Acrylic Laser Cutting Machines Price 60w-150w Laser Wood Cutting Machine PriceUS$ 2,000 - 9,999MOQ: 1 Set
invitation card cutting machiner Main Features
Model |
YN0690X(H)2H(M) |
YN1610X(H)2H(M) |
YN1530(H)2H(M) |
Working Area |
600*900mm |
1600*1000mm |
1500*3000mm |
Laser Power |
60w/80w/100w/130w//150w |
||
Laser Type |
CO2 Sealed Laser Tube,10.6μm |
||
Cooling Type |
Water Cooling |
||
Engraving Speed |
0-60000mm/min |
||
Cutting Speed |
0-40000mm/min |
||
Laser Output Control |
0-100% Set by Software |
||
Min.Engraving Size |
Chinese:2.0mm*2.0mm,English Letter:1.0mm*1.0mm |
||
Highest Scanning Precision |
4000DPI |
||
Locating Accuracy |
≤+0.01mm |
||
Controlling Software |
DSP Control System |
||
Graphic Format Supported |
DST PLT BMP DXF DWG AI LAS,etc |
||
Compatible Software |
CORELDRAW,PHOTOSHOP,AUTOCAD,TAJIMA,etc. |
||
Color Separation |
Yes |
||
Drive System |
High-precision 3-phase Stepper Motor |
||
Auxiliary Equipments |
Exhaust Fan and Air Exhaust Pipe |
||
Power Supply |
AC110V/220V+10%,50HZ/60HZ |
||
Working Environment |
Temperature:0-45C,Humidity5-95%(No Condensate Water) |
||
invitation card cutting machiner Advantages:c laser engraving machine price
|
1. 64-bit processor:It adopts the internationally advanced 64 digits, high speed DSP for control system of the GS laser engraving machine. The processing Capability and stability is highly improved. 2. Optimization of Arc:Stable S-style speed control software, quick and stable motion, which go very well with the automatic laser compensation, all these help the machine do a good job when cutting different parts ,like straight lines, angles. 3. USB Interface:It supports the USB interface, with the GS series laser engraving machine, it’s not necessary to connect to the computer, in this case, it not only enjoys high anti-interference, but also you can use only one computer to control many laser engraving machines |
invitation card cutting machiner parts
After-sales service: CD, Video, User Manual to guide you how to install, operate, maintaince
Standard accessories:
1) 1×Air pump for Air Assist ( for blowing off debris as the laser engrave or cut)
2) 1×Exhaust fan with Tube ducts (install inside machine)
3) 1×Industrial chiller
4) 1×USB Cable (connecting PC and laser)
5) 1×DVD (including software, user manual, guiding videos etc)
6) 2×Power cables
7) 1×Tool box
1. 12 months for machine,long life span of laser tube:1500-3000 hours.
2. 24 hours technical support by e-mail, calling or door-to-door service
3 .English software, user manual and detailed Videos CD
4.International quality certificate:CE,FDA
5. professional laser machine supplier with 8 years experiences in China
We offer training in our factory.Welcome to our factory .
Machine packing
