Specifications
Heat treatment ovenPID automatic control;
High purity alumina fiber;
Fast rate of temperature increasing;
CE certified
Model: KJ-1200VF/KJ-1600VF Vacuum heat treatment oven
Size(mm, WxHxD): 150x150x150 (6"x6"x6") / 200x200x200 (8"x8"x8").
Heat treatment oven features
1. In KJ-1200VF, Operation Temperature: 1100°C,(1200°C for short time);
In KJ-1600VF, Operation Temperature: 1500°C,(1600°C for short time);
2. Maximum energy efficiency is achieved by surrounding the chamber with thermal-efficient alumina fiber ceramic insulation.
3. Heavy duty double layer structure with cooling fan. Lower teperature in outside case.
4. PID automatic control via current limiting phase angle fired the resistor, e.g. SCR(Silicon Controlled Rectifier).
5. Power control with 30 segments programmable.
6. Widely used in the heat treatment of metallic material in coarse vacuum, in reducibility or protective atmosphere.
7. Can also be used for special heat treatment of materials, such as carbon products in the development process of carbonation.
Heat treatment oven descriptions
Model |
KJ-1200VF |
KJ-1200VF |
KJ-1600VF |
KJ-1600VF |
Working Temp. |
1100°C |
1100°C |
1500°C |
1500°C |
Max. Temp. |
1200°C |
1200°C |
1600°C |
1600°C |
Temp. Accuracy |
+/-1°C |
+/-1°C |
+/-1°C |
+/-1°C |
Chamber (mm,WxHxD) |
150x150x150 |
200x200x200 |
150x150x150 |
200x200x200 |
Heating Element |
Resistance wire |
Resistance wire |
MoSi2 Rods |
MoSi2 Rods |
Final vacuum |
15pa |
15pa |
15pa |
15pa |
Pressure rising rate |
≤10-20pa/h |
≤10-20pa/h |
≤10-20pa/h |
≤10-20pa/h |
Max. Power |
3kw |
7kw |
4kw |
8kw |
Package: Plastic paper inside, Polyfoam filled, Wooden box outside.
Payment: T/T, West union, etc.
Shipping and Delivery: by air/sea, in 15 days after receiving the payment
Warranty: 1 year limited warranty on all electronic parts.
