Help CenterElectric Heating VCD System Vacuum Heat Treatment Furnace
Related Products
-
Hot Sale Vacuum Heat Treatment FurnaceUS$ 1,300 - 26,000MOQ: 1 Set -
Vacuum Heat Treatment Furnace Induction Melting FurnaceUS$ 1,300 - 26,000MOQ: 1 Set
-
Good Performance Vacuum Heat Treatment Furnace for Bright Tempering and AnnealingUS$ 1,300 - 26,000MOQ: 1 Set
-
Vacuum Heat Treatment Oven/glass Melting Furnace OvenUS$ 1,200 - 24,000MOQ: 1 Set
-
Vacuum Heat Treatment Oven/high Vacuum FurnaceUS$ 1,200 - 24,000MOQ: 1 Set
Specifications
Vacuum heat treatment furnace for sintering,quenching,annealingHigh quality fiber board ad PID contro;
Water-cooling way;
Model: KJ-1200VF/KJ-1600VF Vacuum heat treatment furnace
Size(mm, WxHxD): 150x150x150 (6"x6"x6") / 200x200x200 (8"x8"x8").
Vacuum furnace features
1. In KJ-1200VF, Operation Temperature: 1100°C,(1200°C for short time);
In KJ-1600VF, Operation Temperature: 1500°C,(1600°C for short time);
2. Maximum energy efficiency is achieved by surrounding the chamber with thermal-efficient alumina fiber ceramic insulation.
3. Heavy duty double layer structure with cooling fan. Lower teperature in outside case.
4. PID automatic control via current limiting phase angle fired the resistor, e.g. SCR(Silicon Controlled Rectifier).
5. Power control with 30 segments programmable.
6. Widely used in the heat treatment of metallic material in coarse vacuum, in reducibility or protective atmosphere.
7. Can also be used for special heat treatment of materials, such as carbon products in the development process of carbonation.
Vacuum furnace descriptions
Model |
KJ-1200VF |
KJ-1200VF |
KJ-1600VF |
KJ-1600VF |
Working Temp. |
1100°C |
1100°C |
1500°C |
1500°C |
Max. Temp. |
1200°C |
1200°C |
1600°C |
1600°C |
Temp. Accuracy |
+/-1°C |
+/-1°C |
+/-1°C |
+/-1°C |
Chamber (mm,WxHxD) |
150x150x150 |
200x200x200 |
150x150x150 |
200x200x200 |
Heating Element |
Resistance wire |
Resistance wire |
MoSi2 Rods |
MoSi2 Rods |
Final vacuum |
15pa |
15pa |
15pa |
15pa |
Pressure rising rate |
≤10-20pa/h |
≤10-20pa/h |
≤10-20pa/h |
≤10-20pa/h |
Max. Power |
3kw |
7kw |
4kw |
8kw |
Package: Plastic paper inside, Polyfoam filled, Wooden box outside.
Payment: T/T, West union, etc.
Shipping and Delivery: by air/sea, in 15 days after receiving the payment
Warranty: 1 year limited warranty on all electronic parts.
Service:
1,reply your inquiry at the first seconds
2,answer your question sincerely
3,to satisfy your requirement
4,deliver products timely
5,We will offer the tracking No.for checking the status we ship the goods.
