Molybdenum Disilicide(MoSi2) Heating Element
US$ 1 - 100
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Brand Name:
KJ heating elements
Model Number:
KJ-1800-1400-1200C
Place of Origin:
Henan, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
W Shape MoSi2 Rod Used for Furnace and Kiln(Favorable Price)US$ 6 - 107MOQ: 1 Piece -
Top Quality I/U/H Shape MoSi2 Heating Element/Molybdenum Disilicide Heating ElementUS$ 1 - 100MOQ: 10 Pieces
-
Furnace Heating RodUS$ 1 - 100MOQ: 10 Pieces
-
MoSi2 Heating ElementsUS$ 1 - 100MOQ: 10 Pieces
-
U and W Type MoSi2 Heating Elements With High Temperature ResistantUS$ 1.7 - 210MOQ: 10 Pieces
Brand Name
KJ heating elements
Model Number
KJ-1800-1400-1200C
Place of Origin
Henan, China
Specifications
MoSi2 hearting element1.Work tem:1300-1800C
2.Type:I, L,U,h,W,UL
3.Dia:3/6,4/9,6/12,9/18,12/24mm
4.Long life,high perferman
Molybdenum Disilicide(MoSi2) heating elements
Material Grade of the heating element: M1700/M1800
d: Hot Zone Diameter
c: Cold Zone Diameter
Le: Hot Zone Length
Lu: Cold Zone Length
a: Shank Spacing
If you have the special requirement for the resistance, please tell us!
Order Sample
U Shape, Material Grade: M1700,
d-4mm, c-9mm, Le-450mm, Lu-450mm, a-25mm
Specify As: KJ-MoSi2-U, 4/9×450×450×25
Molybdenum Disilicide(MoSi2) heating elements
Descriptions
| 1700°C Grade | 1800°C Grade | |||||||||
| d/c (mm) | 3/6 | 4/9 | 6/12 | 9/18 | 12/24 | 3/6 | 4/9 | 6/12 | 9/18 | 12/24 |
| Le Max,mm | 350 | 450 | 1400 | 1400 | 1700 | 350 | 450 | 1400 | 1400 | 1700 |
| Lu Max,mm | 300 | 450 | 1000 | 1000 | 1000 | 300 | 450 | 1000 | 1000 | 1000 |
| a (mm) | 25 | 25 | 40/50 | 60 | 80 | 25 | 25 | 40/50 | 60 | 80 |
| f (mm) | 25 | 25 | 45 | 75 | 100 | 25 | 25 | 45 | 75 | 100 |
| g (mm) | 15 | 15 | 25 | 30 | 40 | 15 | 15 | 25 | 30 | 40 |
| Nonstandard size could be made according to your requirement. | ||||||||||
Welcome to pay close attation to our other furnace: Tube furnaces, (Vacuum) Crucible furnaces, Vacuum Box furnace, Double(Multi) zones Tube furnaces, Multi-position Rotary Tube furnace, Bottom Loading furnace, MoSi2 heating elements, SiC heating elements, etc.
