Specifications
Nitrogen degassing furnacePID automatic control
Double layer
Professional manufacturer
Inert gas
Model: KJ-1600A Nitrogen Degassing Furnace
Size: All standard sizes, and made-to-order
Features of Nitrogen Degassing Furnace
1. Operation Temperature: 1500°C (1600°C for short time).
2. Maximum energy efficiency is achieved by surrounding the chamber with thermal-efficient alumina fiber ceramic insulation.
3. Heavy duty double layer structure with cooling fan. Lower teperature in outside case.
4. PID automatic control via current limiting phase angle fired the resistor, e.g. SCR(Silicon Controlled Rectifier).
5. Power control with 30 segments programmable.
Technical Parameters of Nitrogen Degassing Furnace
| Chamber Size | All standard sizes and Made-to-order |
| Working Temperature | 1500°C (continuous) |
| Maximum Temperature | 1600°C (for short time) |
| Furnace Atomsphere | Nitrogen, Argon and other inert gas |
| Temperature Control | 30 steps programmable and PID automatic control |
| Heating Rate | 0~15°C/min (suggestion: 0--10°C) |
| Temperature Accuracy | +/-1°C |
| Heating Element | Molybdenum Disilicide (MoSi2) |
| Working Voltage | AC 220V, Single Phase, 60/50 Hz (or according to your requirement) |
| Max. Power | 6 KW |
| Outside Size | 550x540x820mm |
| Net Weight | 200 Kg |
Standard sizes
| Model | Chamber size (WxHxD mm) |
| KJ-1600A | 150x150x150mm (6"x6"x6") |
| KJ-1600A | 150x150x200mm (6"x6"x8") |
| KJ-1600A | 200x200x200mm (8"x8"x8") |
| KJ-1600A | 200x200x300mm (8"x8"x12") |
| KJ-1600A | 250x250x300mm (10"x10"x12") |
| KJ-1600A | 300x300x400mm (12"x12"x16") |
| KJ-1600A | 350x350x400mm (14"x14"x16") |
| KJ-1600A | 400x400x400mm (16"x16"x16") |
| KJ-1600A | 500x500x500mm (20"x20"x20") |
| Nonstandard size could be made according to your requirement. | |
