Specifications
Atmosphere industrial furnacePID automatic control
For university,research institutions and lab
Alumina ceramics fiber
KJ-1200A industrial atmosphere furnace
All the hearth material are made by the imported Morgen Fiber, and its effect of energy-saving is
more that 80% of the old furnace.
Our products have the advantages warming faster 20-40 mins, energy saving,
high precision temperature control, heat preservation performance , the microcomputer control,
programmable automatic temperature, temperature at furnace wall to such high interest conditions,
Widely used in ceramic industry, chemical industry, electronic, metallurgy, new materials, machinery,
fire-proof material, building materials, special materials of experiment and production. welcome old and new customers.
The following specifications can be produced according to the costumer’s need
|
Specifications |
StandardWorking Temperature(C) |
Max .Temperature |
Inside Chamber Size (WxHxD mm) |
Max. Power (KW) |
Working Voltage(V) |
KJ-1200A |
1100oC ( continuous ) |
1200C( < 3 hrs) |
150x150x150 |
2KW |
220V |
KJ-1200A |
1100oC ( continuous ) |
1200C( < 3 hrs) |
150x150x200 |
4KW |
220V |
KJ-1200A |
1100oC ( continuous ) |
1200C( < 3 hrs) |
200x200x200 |
5KW |
220V |
KJ-1200A |
1100oC ( continuous ) |
1200C( < 3 hrs) |
200x200x300 |
6KW |
220V |
KJ-1200A |
1100oC (continuous ) |
1200C( < 3 hrs) |
250x250x300 |
8 KW |
220V |
KJ-1200A |
1100oC ( continuous ) |
1200C( < 3 hrs) |
300x300x400 |
10 KW |
220V |
(Controlled by the computer)They can be programmed, and the temperature will increase automatically, with an accuracy of temperature controlling:±1C
|
This furnace can protect materials from oxidation and decarburization with flowing Nitrogen, Argon and other Inert gas.It’s an ideal furnace for sintering, reducing with inert-atmosphere in labs of university, Research Institution and industrial company.
| |
Inside Chamber Size: |
450x450x500mm(18"x18"x20") |
Standard Working Temperature: |
1100oC ( continuous ) |
Maximum Working Temperature: |
1200oC ( < 3 hrs) |
Furnace Atmosphere: |
Nitrogen, Argon and other inert gases |
Temperature Control: |
30 steps programmable and PID automatic control |
Heating Rate: |
0~ 10.C/ min (suggestion: =< 10.C ) |
Temperature Accuracy: |
+/- 1 .C |
Furnace structure: |
double shell with fan cooling |
Heating Element: |
Fe-Cr-Al-Mo wire/Kanthal resistance wire |
Thermocouple: |
K type |
Working Voltage: |
AC 220V Three Phases 60/50 Hz (or according to your requirement) |
Applications of atmosphere industrial furnace:
1.Gravimetric analysis;
2.Sintering or Roasting or Forging or calcining;
3.Quantitative analysis;
4.Heat treating or Preheating;
5.Quenching or Hardening or Austempering
6.Annealing or Tempering or Normalizing
7.Stress Relieving
8.Temperature measurement
Sample Specifications:
1.Inside Chamber Size:450x450x500mm(18"x18"x20")
2.Standard Working Temperature:1100.C ( continuous )
3.Maximum Working Temperature:1200.C ( < 3 hrs)
4.Furnace Atmosphere: Nitrogen, Argon and other inert gases
5.Heating Element :Fe-Cr-Al-Mo wire/Kanthal resistance wire
6.Thermocouple:K type
