N2XSY, Power Cable, 6/10 KV, 1/C, Cu/XLPE/CWS/CTS/PVC (HD 620 10C/VDE 0276-620)
US$ 5 - 60
MOQ: 150 Meters
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
DingAn
Model Number:
N2XSY
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Cu/XLPE/CTS/PVC/AWA/PVC, Power Cable, 19/33 KV, 1/C (BS 6622)US$ 10 - 35MOQ: 100 Meters -
NA2XS2Y, Power Cable, 6/10 KV, 1/C, Al/XLPE/Cws/PE (HD 620/VDE 0276-620)US$ 4 - 23MOQ: 500 Meters
-
N2XS(F)2Y, 18/30 kV Power Cable, 1/C, Cu/XLPE/Cws/PE (HD 620/VDE 0276-620)US$ 6.5 - 70MOQ: 150 Meters
-
NA2XS(F)2Y, 18/30 kV Power Cable, 1/C, Al/XLPE/CWS/CTS/PE (HD 620 10C/VDE 0276-620)US$ 3.5 - 30MOQ: 200 Meters
-
NA2XSY, Power Cable, 12/20 KV, Al/XLPE/Cws/PVC (HD 620/VDE 0276-620)US$ 4 - 26MOQ: 500 Meters
Place of Origin
Jiangsu, China
Brand Name
DingAn
Model Number
N2XSY
Insulation Material
XLPE
Type
Medium Voltage
Application
Power Station
Conductor Material
Copper
Jacket
PVC
Product Description
N2XSY, Power Cable, 6/10 KV, 1/C, CU/XLPE/CWS/CTS/PVC (HD 620 10C/VDE 0276-620)
Technical Data:
conductor material: bare copper
conductor material: bare copper
conductor construction: stranded, class 2
insulation: XLPE DIX8
sheathing material: PVC DMV6
flame retardant: VDE 0482-332-1-2/IEC 60332-1
maximum temperature at conductor: 90 °C
max. operating temperature, fixed: +70 °C
temperature, moved/during installation: -5 - +70 °C
bending radius, fixed installation: 15 x DA
partial discharge: 2 pC
nominal voltage Uo: 6 kV
nominal voltage U: 10 kV
maximum permitted operating voltage in 3-phase systems:12 kV
test voltage: 21 kV
Application:
For installation in ground, in water, outdoors, indoors and in cable ducts for power stations, industry, and
For installation in ground, in water, outdoors, indoors and in cable ducts for power stations, industry, and
distribution networks. The good installation properties of this cable make installation easy, even on difficult routes. Acc.
| Number of cores and cross-section | Shape of conductor | Conductor diameter | Nominal insulation thickness | Diameter over insulation | Nominal thickness sheath | Outer diameter (approx.) | Bending radius (min.) | Weight (approx.) |
| (approx.) | (approx.) | |||||||
| mm2 | mm | mm | mm | mm | mm | mm | kg/km | |
| 1x35/16 | RM | 7.2 | 3.4 | 15.3 | 2.5 | 24 | 360 | 904 |
| 1x50/16 | RM | 8.2 | 3.4 | 16.3 | 2.5 | 26 | 390 | 1039 |
| 1x70/16 | RM | 9.8 | 3.4 | 17.9 | 2.5 | 27 | 405 | 1271 |
| 1x95/16 | RM | 11.3 | 3.4 | 19.4 | 2.5 | 29 | 435 | 1530 |
| 1x120/16 | RM | 12.8 | 3.4 | 20.9 | 2.5 | 30 | 450 | 1809 |
| 1x150/25 | RM | 14.2 | 3.4 | 22.3 | 2.5 | 32 | 480 | 2158 |
| 1x185/25 | RM | 15.8 | 3.4 | 23.9 | 2.5 | 33 | 495 | 2524 |
| 1x240/25 | RM | 18.3 | 3.4 | 26.4 | 2.5 | 36 | 540 | 3117 |
| 1x300/25 | RM | 20.7 | 3.4 | 28.8 | 2.5 | 38 | 570 | 3786 |
| 1x400/35 | RM | 23.3 | 3.4 | 31.4 | 2.5 | 41 | 615 | 4750 |
| 1x500/35 | RM | 26.5 | 3.4 | 34.6 | 2.5 | 44 | 660 | 5786 |
Packaging & Shipping
