Cu/XLPE/CTS/PVC/AWA/PVC, Power Cable, 19/33 KV, 1/C (BS 6622)
US$ 10 - 35
MOQ: 100 Meters
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
DingAn
Model Number:
CU/XLPE/CTS/PVC/AWA/PVC
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
NA2XS2Y, Power Cable, 6/10 KV, 1/C, Al/XLPE/Cws/PE (HD 620/VDE 0276-620)US$ 4 - 23MOQ: 500 Meters -
N2XS(F)2Y, 18/30 kV Power Cable, 1/C, Cu/XLPE/Cws/PE (HD 620/VDE 0276-620)US$ 6.5 - 70MOQ: 150 Meters
-
NA2XS(F)2Y, 18/30 kV Power Cable, 1/C, Al/XLPE/CWS/CTS/PE (HD 620 10C/VDE 0276-620)US$ 3.5 - 30MOQ: 200 Meters
-
NA2XSY, Power Cable, 12/20 KV, Al/XLPE/Cws/PVC (HD 620/VDE 0276-620)US$ 4 - 26MOQ: 500 Meters
-
N2XS(F)2Y, Water Resistant Power Cable, 12/20 KV, 1/C, Cu/XLPE/CWS/CTS/PE (HD 620/VDE 0276-620)US$ 6 - 66MOQ: 500 Meters
Place of Origin
Jiangsu, China
Brand Name
DingAn
Model Number
CU/XLPE/CTS/PVC/AWA/PVC
Insulation Material
XLPE
Type
Medium Voltage
Application
Construction
Conductor Material
Copper
Jacket
PVC
Product Description
Cu/XLPE/CTS/PVC/AWA/PVC, Power Cable, 19/33 KV, 1/C (BS 6622)
Application
Power cables for power networks, underground and in cable ducting.
Standards
BS6622
Technical Data
Technical Data
Conductor
Class 2 stranded plain copper conductor to BS EN 60228:2005 (previously BS6360)
Conductor Screen
Semi-conducting material
Insulation
XLPE (Cross-Linked Polyethylene) Type GP8 to BS7655
Insulation Screen
Semi-conducting material
Metallic Screen
Individual and overall copper tape screen to BS6622
Filler
PETP (Polyethylene Terephthalate) fibres
Separator
Binding tape
Bedding
PVC (Polyvinyl Chloride) Type TM1 to BS7655
Armouring
Single Core: AWA (Aluminium Wire Armoured)
Sheath
PVC (Polyvinyl Chloride) Type TM1 to BS7655
Sheath Colour
Red or Black
Voltage Rating
19000/33000V
Temperature Rating
0°C to +90°C
Minimum Bending Radius
Single Cores: 15 x overall diameter
| No. of Cores x Nominal Cross Sectional Area | Nominal Diameter | Nominal Weight | ||
| Under Armour | Over Armour | Overall | ||
| # x mm² | mm | kg/Km | ||
| 1 x 70 | 32.6 | 36.6 | 41.0 | 2300 |
| 1 x 95 | 34.3 | 38.3 | 42.9 | 2650 |
| 1 x 120 | 35.9 | 39.9 | 44.5 | 3000 |
| 1 x 150 | 37.5 | 42.5 | 47.3 | 3500 |
| 1 x 185 | 39.3 | 44.3 | 49.3 | 4000 |
| 1 x 240 | 41.7 | 46.7 | 51.7 | 4650 |
| 1 x 300 | 44.2 | 49.2 | 54.4 | 5450 |
| 1 x 400 | 47.3 | 52.3 | 57.7 | 6350 |
| 1 x 500 | 50.5 | 55.5 | 61.1 | 7600 |
| 1 x 630 | 54.2 | 59.2 | 65.0 | 9150 |
| 1 x 800 | 60.5 | 65.5 | 71.6 | 11100 |
| 1 x 1000 | 65.0 | 70.0 | 76.5 | 13400 |
