Specifications
wood pellet millCE Certificate
12years experience
High capacity
biomass fuel and wood pellet mill
biomass fuel and wood pellet mill
1.high quality
2.low price
3.easy operation
biomass fuel and wood pellet mill
Biomass is a general term used to describe any organic material which can be used as a fuel. For example wood, wood waste, energy crops and agricultural waste such as straw. A biomass pellet mill has variable features that make it possible to process various biomass materials. For example the pellet mill must have sufficient power to process woody biomass, and also the ability to control features such as die speed. At PelHeat we develop small mobile biomass pellet mills to process a wide range of biomass materials. The uses for these pellets could be as fuel, animal feed, animal bedding and even cooking pellets. A biomass pellet mill is a general term to describe a pellet mill, however some pellet mills have specific features for processing certain materials.
Grass Pellet Mill
Grass pellet mills are used predominantly in the animal feed industry. Grass pellet mills generally have a higher die speed than wood pellet mills for example. Also energy consumption is much lower, due to the reduced resistance of the grass.
Wood Pellet Mill
One of the key differences with wood pellet mills is the difference in die rotation speed. Wood has a much higher density than grass for example, and so is more difficult to process into pellets. More power is required to process wood into pellets, therefore traditionally a lower gearing is required to compress the wood through the die. Also to gelatinise wood into pellets, higher production temperatures are required. Raw material temperature can be increased by processing the raw material through a steam conditioner. However another way to increase pellet quality is to increase resonance time through the die, hence a lower die rotation speed.
SKJ250 type
Motor: YL180L6 15 kw
Flat die diameter: 250mm
Pore size: diameter 2.5mm, diameter 3mm, diameter 4mm, 6mm diameter
Flat die speed: 366r/min
Particle moisture content: less than 10% of raw materials
Particle production :250-500kg / h (mode pore diameter of 4mm)
Body weight: 175kg
SKJ320 type
Motor: Y225M-6 30kw
Flat die diameter: 320mm
Pore size: diameter of 3mm, diameter 4mm, diameter 6mm, 8mm diameter
Flat die speed: 300r/min
XKJ320
Motor: 22 kW, speed 970r/min
Flat die diameter: 320 mm
Flat die speed: 300r/min
Die diameter: diameter 2-20 (mm)
Body size: length × width × height 150 × 65 × 130 (cm)
Body weight: about 300 kg
Output:500-600kg/h
XKJ420 type
Motor: Y-250M6 37 kW, speed 970r/min
Flat die diameter: 420 mm
Flat die speed: 300r/min
Die Hole Size Diameter 2-20 (mm)
Body size: length × width × height 180 × 100 × 160 (cm)
Body weight: about 400 kg
Output:600-1000kg/h
