USE-2, Building Wire, 600 V, Tinned Cu/XLPE/Lszh (UL 854)
US$ 2 - 33
MOQ: 500 Meters
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
OEM
Model Number:
USE-2
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Thw, Building Wire, PVC Insulated Wire (UL 83)US$ 0.10 - 0.10MOQ: 1000 Meters -
Quadruplex Secondary UD, 600 V Building Cable, Al/XLPE (ANSI/ICEA S-105-692)US$ 0.3 - 5MOQ: 500 Meters
-
Triplex Secondary URD, URD Cable, 600 V, Al/XLPE (ANSI/ICEA S-105-692)US$ 0.3 - 15MOQ: 500 Meters
-
CVV, Control Cable, 600 V, Cu/PVC/PVC (IEC 60502-1)US$ 0.3 - 25MOQ: 500 Meters
-
Classic 110, Control Cable, Flexible CU/PVC/PVC, 300/500 V (DIN VDE 0281)US$ 1 - 10MOQ: 500 Meters
Place of Origin
Jiangsu, China
Brand Name
OEM
Model Number
USE-2
Insulation Material
XLPE
Type
Low Voltage
Application
Industrial
Conductor Material
Copper
Jacket
Other, LSZH
Product Description
USE-2, Building Wire, 600 V, Tinned Cu/XLPE/LSZH (UL 854)
Product Construction:
Conductor: Tinned Copper per ASTM B33/Class B per ASTM B8
Insulation: XLPE
Jacket: black Low-smoke, Zero-Halogen Cross-linked Polyolefin (LSZH XLPO)
Applications:
Conductor is suitable for use as underground service entrance cable for direct burial at conductor temperatures not to exceed 90°C
Compliances:
Industry Compliances:
UL 854
Limited Smoke rating per UL 44 and UL 1685
ICEA T-33-655 smoke, halogen and acid gas requirements
ICEA S-95-658/NEMA WC70
| Size | Number of Conductor Wires | Conductor Diameter | Insulation Thickness | Jacket Thickness | Cable Weight |
| AWG/KCMIL | mm | mm | mm | kg/km | |
| 14 | 7 | 1.78 | 0.76 | 0.38 | 36 |
| 12 | 7 | 2.29 | 0.76 | 0.38 | 49 |
| 10 | 7 | 3.05 | 0.76 | 0.38 | 71 |
| 8 | 7 | 3.81 | 1.14 | 0.38 | 115 |
| 6 | 7 | 4.57 | 1.14 | 0.79 | 182 |
| 4 | 7 | 5.84 | 1.14 | 0.79 | 265 |
| 2 | 7 | 7.37 | 1.14 | 0.79 | 394 |
| 1/0 | 19 | 9.4 | 1.4 | 1.14 | 628 |
| 2/0 | 19 | 10.41 | 1.4 | 1.14 | 771 |
| 4/0 | 19 | 13.21 | 1.4 | 1.14 | 1168 |
| 250 | 37 | 14.22 | 1.65 | 1.65 | 1429 |
| 350 | 37 | 17.02 | 1.65 | 1.65 | 1933 |
| 500 | 37 | 20.32 | 1.65 | 1.65 | 2683 |
| 750 | 61 | 24.62 | 2.03 | 1.65 | 3965 |
| 1000 | 61 | 28.7 | 2.03 | 1.65 | 5936 |
