300Mbps OpenWRT Wifi Repeater / AR 9341 WiFi Repeater Openwrt Repeater

Name: 300Mbps OpenWRT Wifi Repeater / AR 9341 WiFi Repeater Openwrt Repeater
Brand: TopDoss
SKU: 116443395

US$ 30 - 40 MOQ: 50 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

TopDoss

Model Number:

TD-AP

Shenzhen TopDoss Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name TopDoss

Model Number TD-AP

Specifications

1.300Mbps OpenWRT Wifi repeater / AR 9341 WiFi repeater Openwrt repeater
2. Openwrt
3.support openwrt
4.Fast delivery

300Mbps OpenWRT Wifi repeater/AR 9341 WiFi repeater Openwrt repeater

Hardware Specifications
Features	Instructions
CPU	AR9341
DDR	32/64Mbyte
Flash memory	8Mbyte
PoE power	Support POE Power,Compatible 12V DC
CPU Frequency	535MHz
Wireless Configuration	2×2 (2Tx,2 Rx)
Ethernet Interface	1 Base Ethernet Ports
Ethernet Physical Rate	10/100Mbps
Reset Button	The device to restore factory settings
Power Supply	12VDC@2A or POE af/at Standard
Modulation Mode	OFDM/BPSK/QPSK/CCK/DQPSK/DBPSK
Frequency Range	China : 2412 GHz ~ 2484 GHz (Chanel1-Chanel13)
Power Consumption	< 9W
RF Power @25°C (±1.5dB)	802.11b	30 ± 2dBm
	802.11g	6-9Mbps			30± 2dBm
		12-18Mbps			28± 2dBm
		24-36Mbps			27± 2dBm
		48-54Mbps			26± 2dBm
	802.11n	HT20	MCS 0-3		29 ± 2dBm
			MCS 4		28 ± 2dBm
			MCS 5		26 ± 2dBm
			MCS 6		25 ± 2dBm
			MCS 7		25± 2dBm
		HT40	MCS 0-3		29 ± 2dBm
			MCS 4		28 ± 2dBm
			MCS 5		26± 2dBm
			MCS 6		25 ± 2dBm
			MCS 7		25 ± 2dBm
Sensitivity	IEEE 802.11b 1Mbps<-93dBm 11Mbps<-87dBm	IEEE 802.11g 6Mbps<-91dBm 54Mbps<-72dBm		IEEE 802.11n HT 20 MCS 0<-85dBm MCS 7<-67dBm HT 40 MCS 0<-82dBm MCS 7<-64dBm

Physical Specifications
Features	Instructions
Dimension	120MM(Diameter)×52MM(height)
Weight	<200g
Environmental Specifications
Features	Instructions
Operating Humidity	0%--90% No-condensing
Operating Temperature	-15--+55°C
Storage Temperature	-20--+60°C
