Slag Mill,slag Grinding Mill

Slag Mill,slag Grinding Mill thumbnail-1
Slag Mill,slag Grinding Mill photo-1
US$ 5,000 - 99,999 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Slag mill
Motor Type:
AC Motor
Contact Supplier Request Quote Chat Now
Luoyang Zhongrong Machinery Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin Shanghai or others
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, Slag mill
Motor Type AC Motor
Power(W) 2000
Capacity(t/h) 3-35 t/h
Place of Origin Henan, China
Brand Name Zhongrong
Model Number Slag mill as per specification
Dimension(L*W*H) As per specification
Weight As per specification
Certification ISO,CE, ISO, CE
Warranty One year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1. ISO/CE approved
2.Evener granularity
3. Less over crushed products
4. High product capacity



Product Description

Product Introduce of Slag mill :

Slag mill is the key equipment for double grinding after the pre-crushed slag, it has been widely used in powder grinding industry and cement grinding station, the technology is very mature.



Application Range of Slag mill :

It is widely used for grinding granulated blast furnace slag, also for grinding cement clinker.



Working Principle of Slag mill :

The slag in the mill are squeezed and ground under the pressure of the roller, the ground materials are blown to the separator by the hot wind for separating, meanwhile, it is dried by the hot wind. The separated fines are collected to the duster, sent through air chute, storage elevator, and the three-way valve storage chute, then saved in the powder base. Part of the airflow are purified and circled back, the rest go into the atmosphere through the exhaust fan and the chimney. The coarse materials are sent back the mill for regrind. There outer circling system of the slag mill device. The coarse material which could not be blow up by the airflow will be sent to the cinder through Double flap valve, belt conveyor, elevator. The material in the cinder will be resent to the mill through the belt conveyor, vibrating feeder etc.



Technical date of Slag mill :



Spec./m

 (Dia.×Length)

Speed

(r/min)

Feeding Size
(mm)

Capacity

(t/h)

Griding Media Loading

(t)

Main Motor

 (KW)

Main Reducer

Weight
 (t)

1.83×7.0

23.8

<20

3~5

22

245

ZD60

43.5

1.83×9.5

24.1

<20

5~7

31

355

ZD70

56

2.2×9.5

21.5

<20

8~10

41

475

ZD70

74

2.2×11

21.5

<20

10~12

50

570

ZD80

109

2.4×11

20.3

<20

12~14

57

630

ZD80

116

MBY560

2.4×13

20.3

<20

14~16

68

800

MBY710

138

JDX710

2.6×11

19.7

<20

15~16

69

800

MBY710

138

JDX710

2.6×13

19.7

<20

16~18

82

1000

MBY800

158

JDX800

3.0×12

18.2

<20

18~20

100

1250

MBY800

182

JDX800

3.0×13

18.2

<20

21~23

108

1400

MBY900

190

JDX900

3.2×13

17.8

<20

25~27

128

1600

MBY1000

230

JDX1000

3.2×14

17.8

<20

28~30

138

1800

MBY1000

249

JDX1000

3.5×13

17.3

<20

32~35

156

2000

JS130-A

275



 More specification details please contact us directly.



Process capacity

Slag mill,slag grinding mill





Packaging & Shipping

Packaging:  Cement mill body in bulk , motor and spare parts packed in wooden case.

Slag mill,slag grinding mill



Customer Visit

Slag mill,slag grinding mill



Our Services

Professional mining equipment supplier with one-site service, Supply range is as follows:



Ore Dressing Equipment: Cement Mill, Slag Mill, Rod Mill, Ball Mill

Crushing/Screening Equipment: Jaw Crusher, Cone Crusher, Impact Crusher, Hammer Crusher, Crushing Plant, Vibrating Screen

Hoisting/Conveyor Equipment: Conveyor, Hoister,

Washing Equipment: Classifier, Flotation Equipment, Magnetic Separator



Installation and commissioning:

If installation and commissioning service is requested, technical person will go to user’s working site for support. Details will be negotiated.



Quality Guarantee:  Guarantee one year from shipment date.


Technical support: Product specification, Use Manual, Technical data and etc will be provided.


Related Spare parts are serviced.





It would be greatful to provide details below for any mill products that better to choose suitable model for you.

1. What is the material that you grind?

2. What is the capacity?

3. What are the feeding size and the final product size?
