Hot Products Battery Unifi Access Point

Name: Hot Products Battery Unifi Access Point
Brand: TopDoss
SKU: 116439631
Availability: InStock

US$ 1 - 40 MOQ: 50 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

TopDoss

Model Number:

Customized

Shenzhen TopDoss Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name TopDoss

Model Number Customized

(Muban of ap)300mbps wireless battery access point 2.4GHz indoor wireless access point

1.wireless battery access point

2.WAN/LAN/POE Port
3.AP/Repeater/WDS/WISP/Gateway mode
4.Omni antenna,500meter
5.Ralink3052

Specification

Model:TD-AP300 27dBm High Power wifi router with 100M indoor distance, powerfull in wall pass through, with Repeater/AP functions
Hardware wireless battery access point
MCU	RALINK RT3052
RF	2T2R, 300Mbps MIMO tech , comply with IEEE 802.11N standard
Memory	32MB DDR RAM (May extend to 64MB)
Flash	4MB(May extend to 8MB)
Interface	2 x RJ-45 for 10/100 Mbps WAN/LAN Port (Support 12V/24V POE)
	1 x Reset button(Reset & Factory Defaults)
	1 x Power DC Jack
Power	12V(POE 12V/24V)/1A;110V/220V
Antenna	Build in 2PCS Omni 5dbi antenna
Size	16.8*4.5CM
RF
Frequency	802.11b/g/n:
	2.4~2.4835GHz
	U.S.,Europe and Japan product covering 2.400 to 2.4835 GHz,programmable for different country regulations
Modulation	OFDM = BPSK,QPSK, 16-QAM, 64-QAM
	DSSS = DBPSK, DQPSK, CCK
Throughput	300 Mbps
Sensitivity	802.11n(2.4GHz)	802.11g	802.11b
	-90dBm @ MCS0	- 90dBm @ 6Mbps	- 95dBm @ 1Mbps
	-70dBm @ MCS7	- 72dBm @ 54Mbps	- 90dBm @ 11Mbps
	-90dBm @ MCS8
	-68dBm @ MCS15
Output Power		Radio1(WLAN1)
	802.11n(2.4GHz)(± 1.5dBm)	802.11g(± 1.5dBm)	802.11b(±1.5dBm)
	25dBm@ MCS0~2/MCS8~10	25dBm @ 6~24Mbps	25dBm @1~11Mbps
	24dBm @ MCS3/MCS11	25dBm @ 36Mbps
	23dBm @ MCS4/MCS12	22dBm @ 48Mbps
	23dBm @ MCS5/MCS13	22dBm @ 54Mbps
	22dBm @ MCS6/MCS14
	22dBm @ MCS7/MCS15

Software
Operation Mode	Gateway/ AP/ Repeater/ WDS / WISP
Protocol/Standard	IEEE 802.3(Ethernet)
	IEEE 802.3u(Fast Ethernet)
	IEEE 802.11b/g/n(2.4G WLAN)
Wireless	Auto-Channel selection
	Distance Control (802.1x Ack timeout)
	Multiple SSID (4 SSID)
	BSSID
Security	WEP Encryption-64/128/152 bit
	WPA/WPA2 Personal (WPA-PSK using TKIP or AES)
	WPA/WPA2 Enterprise (WPA-EAP using TKIP)
	Hide SSID

Management
System Settings	Web-based configuration (HTTP/Telnet)
Firmware Upgrade	Upgrade firmware via web browser or TFTP
Administration	Admin Password can be configured
System monitoring	Status in hand , useful statistic and Event log
Logs	Supports local logs, logs host, logs file export
Reset	Reset or factory defaults
Backup	Restore settings & configuration of the device to local file
Physical Property
Temperature	Working: 0°C~55°C
	Storage: -20°C to 70°C
Humidity	5%~95% (typical)
Package
OEM
PoE Box & Power Adapter
User Manual
90mm LAN Cable
