[RD-SMY1200]Semi Automatic Die Cutting and Creasing Machine

Name: [RD-SMY1200]Semi Automatic Die Cutting and Creasing Machine
Brand: RuiDa
SKU: 116134589
Availability: InStock

[RD-SMY1200]Semi Automatic Die Cutting and Creasing Machine thumbnail-1

[RD-SMY1200]Semi Automatic Die Cutting and Creasing Machine photo-1

US$ 45,000 - 115,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Type:

Die-cutting Machine

Computerized:

Yes

Contact Supplier Request Quote Chat Now

Pujiang Ruida Industry & Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjing

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Die-cutting Machine

Computerized Yes

Place of Origin Zhejiang, China

Brand Name RuiDa

Model Number RD-SMY1200

Voltage 380v

Power(W) 13.5kw

Dimension(L*W*H) 3650*2100*2100mm

Weight 14t

Certification CE

Warranty 2 years

After-sales Service Provided Engineers available to service machinery overseas

Specifications

- Semi automatic die cutting and creasing machine
- High quality and best service
- Competitive price
- Easy operation

Purpose

RD-SMY series of Semi automatic die cutting and creasing machine is a special equipment for creasing and cutting top grade colorful boxes and cartons, the machine combines the advantages from the other die cutting and creasing machine which comes from domestic and oversea. Applicable to printing packaging decoration and plastic industries. The machine is characterized by compact strrctute, fine workmanship, high precision and easy operation, etc.

Specification

Model		Unit	RD-SMY1200	RD-SMY1300	RD-SMY1500
Max. paper size		mm	*1200850**	1300*950	1500*1100
Min. paper size		mm	*500400**	500*400	550*450
Max. die cutting szie		mm	*1180845**	1280*945	1495*1095
Min. size of gripper in mouth		mm	6	6	6
Max. die cutting pressure		N/cm²	250	300	320
Available cardboard	Ordinary paperbaord	g/mm²	200-2000	200-2000	200-2000
Available cardboard	Corrugated cardboard	mm	8	8	8
Die cutting precision		mm	±0.1	±0.1	±0.1
Max. die cutting speed		sheets/h	4500	4500	4500
Max. feeding height		mm	1300	1400	1500
Max. collecting height		mm	1100	1250	1350
Total power		kw	13.5	13.5	13.5
Weight		T	14	14.5	17.5
Overall dimension(LWH)		mm	*365021002100*	400023002300	450023002400

Features

Gripper bars with high intensity are applicable to all kinds of cardboard, paperboard and corrugated paper.
Frontal, back and side registration mechanism ensures high precision of die cutting.
Equipped with high precision intermittent device and rapid pneumatic clutch, as well as pneumatic locking mechanism.
Equipped with programmable controller and man-machine interface, which is available to display the running status such as wooking speed, amount of output, running time, etc.
The LCD screen is available to display the machine fault and fault cause, which is convenient for operation.
The main moter is frequency converting controlled, which achieved a stepless speed, and stable running.
The machine is equipped with many safety sensors and dveices, which guarantee the operators safety.
The die cuting pressure on both front and back could be adjusted separately, it's also able to die cutting without clipper margin.

Main drive shaft: the main drive shaft is made of high quality alloy steel with special processed to ensure high precision, long life time and low abrasion.

Pneumatic clutch: Adopt imported pneumatic clutch, long life time, low noise, stable braking, rapid clutching and strong driving force, which conformed to the European standard.

Paper collecting unit: Automatic clollecting paper sheet in order, non-stop pneumatic sample getting system, available to check the die cutting result, also able to alarm and speed down automatically if the collecting is full.

Die cutting unit: The safety design of die cutting baseboard and cutting die, is good for moving, the tuning gear design is very covenient for cutting die changing and adjusting. The baseboard adopts 3mm thick stainless steel, while the active baseplate adopts 2mm aluminium plate.

Main driving chain: The main chain imported from England, adopts heavy loading and high precision transmission chain with high tensile strangth and abrasive resistance. The intermittent device adopts parallel 3-cam indexing mechanism with precision length. The curve of cam is designed specially the can stroke angle is big to achieve smooth running. To ensure safety, the imported overload protector is added between the intermittent device and main driving chain.

Gripper bars: The gripper bars are made of high quality hard alloy aluminum, with the treatment of anode oxidation on the surface, which achieve a strong rigidity and slight weight, which guarantee a high precision paper sheet transmission under the high working speed.
