[RD-ML1100]Die cutting and creasing machine
- 20 Set / Sets per Month
- Tianjin for die cutting and creasing machine
- T/T
-
2016 Style Qingdao A4 Paper Cross Cutting Machine with low price
-
Leizhan Disc sludge thickener for paper pulp making production line
-
High Performance Double DISC Refiner for Paper Pulp Making Machine
-
soft pack facial tissue processing machine paper face facial paper machine napkin tissue machine manufacturer
-
Waterproofing Aluminum Foil Making Machine Wax Paper Food Wrapping Processing machine Baking Paper Making Machine
-
hemp cigarette rolling paper making machine cigarette smoking paper gumming and watermark machine
Product Details
| Condition: | New | Type: | Die-cutting Machine | Computerized: | No |
| Place of Origin: | Zhejiang, China | Brand Name: | RuiDa | Model Number: | RD-ML1100 |
| Voltage: | 380v | Power(W): | 4kw | Dimension(L*W*H): | 1900*1780*1700mm |
| Weight: | 4.5t | Certification: | CE | Warranty: | 2 years |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Purpose
Die cutting and creasing machine is a special equipment for creasing and cutting ordinary cardboard, corrugated cardboard, plastic and leather ingeneral, applicable to printing packaging decoration and plastic industries. The machine is characterized by compact strrctute, fine workmanship, high precision and easy operation, etc.
Features
- Sliding bearings are made of high quality alloy cooper, thus to get effect of anti-frietion and shake reducing.
- Flywheel is with big mlomentof force and heavy pressure.
- High strength due to one piece casting by using top-ranking material for machine frame.
- Single plate electromagnetic clutch is sensitive and reliable.
- With functions of single, continuous and opening dwell operation, dwell range is adjustable.
- Operating position is reasonably arranged, moving-bed can be opened to its optimum.
- Safety system is reliable.
Specification
Model | Max. inner chase size | Working speed | Creasing length | Motor power | Weight | Overall dimension |
mm | strokes/min | mm | KW | T | mm(L*W*H) | |
RD-ML750 | 750*520 | 28±2 | <15 | 2.2 | 2.0 | 1260*1350*1280 |
RD-ML930 | 930*670 | 23±2 | <25 | 3.0 | 3.0 | 1670*1670*1630 |
RD-ML1100 | 1100*800 | 20±2 | <32 | 4.0 | 4.5 | 1900*1780*1700 |
RD-ML1200 | 1200*830 | 20±2 | <35 | 4.0 | 4.8 | 1920*2140*1920 |
RD-ML1300 | 1300*920 | 18±2 | <40 | 5.5 | 6.0 | 2000*2140*2000 |
RD-ML1400 | 1400*1000 | 17±2 | <45 | 5.5 | 6.8 | 2010*2400*1930 |
RD-ML1500 | 1500*1050 | 16±2 | <45 | 5.5 | 7.5 | 2090*2400*1930 |
RD-ML1600 | 1600*1250 | 16±2 | <50 | 11.0 | 11.0 | 2170*2560*2230 |
RD-ML1800 | 1800*1300 | 16±2 | <62 | 15.0 | 13.5 | 2240*2800*2130 |
Lubrication system
Electrical cabinet
Safety control
