Home > Manufacturing & Processing Machinery > Paper Machinery > Paper Making Machine > [RD-AMY1080]Automatic Die Cutting Creasing Machine

[RD-AMY1080]Automatic Die Cutting Creasing Machine

Name: [RD-AMY1080]Automatic Die Cutting Creasing Machine
Brand: RuiDa
SKU: 116134571
Availability: InStock

[RD-AMY1080]Automatic Die Cutting Creasing Machine thumbnail-1

[RD-AMY1080]Automatic Die Cutting Creasing Machine photo-1

US$ 45,000 - 115,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Type:

Die-cutting Machine

Computerized:

Yes

Contact Supplier Request Quote Chat Now

Pujiang Ruida Industry & Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjing/Ningbo/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Die-cutting Machine

Computerized Yes

Place of Origin Zhejiang, China

Brand Name RuiDa

Model Number RD-AMY1080

Voltage 380v

Power(W) 17kw

Dimension(L*W*H) 7650*3900*2150mm

Weight 17.5t

Certification CE

Warranty 2 years

After-sales Service Provided Engineers available to service machinery overseas

Specifications

- Automatic die cutting creasing machine
- High quality and best service
- Competitive price
- Easy operation

Purpose

RD-AMY series of die cutting and creasing machine is a special equipment for creasing and cutting top grade colorful boxes and cartons, the machine combines the advantages from the other die cutting and creasing machine which comes from domestic and oversea. Applicable to printing packaging decoration and plastic industries. The machine is characterized by compact strrctute, fine workmanship, high precision and easy operation, etc.

Specification

Model		Unit	RD-AMY1060	RD-AMY1080	RD-AMY1100	RD-AMY1200
Max. paper size		mm	1060*750	*1080780**	1100*780	1200*780
Min. paper size		mm	400*350	*400370**	400*370	400*370
Max. die cutting szie		mm	1050*730	*1070760**	1090*770	1185*770
Min. size of gripper in mouth		mm	5	5	5	5
Max. die cutting pressure		N/cm²	300	320	320	320
Available cardboard	Ordinary paperbaord	g/mm²	200-350	200-350	200-350	200-350
Available cardboard	Corrugated cardboard	mm	≤4	≤4	≤5	≤5
Die cutting precision		mm	±0.1	±0.1	±0.1	±0.1
Max. die cutting speed		sheets/h	6500	6500	6500	6500
Max. feeding height		mm	1000	1100	1100	1100
Max. collecting height		mm	1000	1100	1100	1100
Total power		kw	13.5	17	17	17
Weight		T	15	17.5	17.8	18
Overall dimension(LWH)		mm	765039002150	*765039002150*	765039002150	580035002100

Features

Equipped with high precision intermittent device, pneumatic locking, pneumatic clutch, overload protection, and manual pressure adjutment device, which guarantee a high speed but stable running.
The machine also equipped with pre-stacking device, sub-feeding unit, variable speed feeding unit, automatic sub-paper collection unit, pneumatic sample getting system, automatic lubrication system, air chilling system for the lubrication of main transmission. All these configureation are ensure a high working efficiency.
The name brand of electrical and transmission components are equipped on this machine, which guarantee a high die cutting precision and stable running.
Equipped with programmable controller and man-machine interface, which is available to display the running status such as wooking speed, amount of output, running time, etc.
The LCD screen is available to display the machine fault and fault cause, which is convenient for operation.
The chilling of power cabinet is achieved by air convection, which ensure the electrical components working stable on a appropriate temperature.
The machine is equipped with many safety sensors and dveices, which guarantee the operators safety.

Main drive shaft: the main drive shaft is made of high quality alloy steel with special processed to ensure high precision, long life time and low abrasion.

Pneumatic clutch: Adopt imported pneumatic clutch, long life time, low noise, stable braking, rapid clutching and strong driving force, which conformed to the European standard.

Paper collecting unit: Automatic clollecting paper sheet in order, non-stop pneumatic sample getting system, available to check the die cutting result, also able to alarm and speed down automatically if the collecting is full.

Die cutting unit: The safety design of die cutting baseboard and cutting die, is good for moving, the tuning gear design is very covenient for cutting die changing and adjusting. The baseboard adopts 3mm thick stainless steel, while the active baseplate adopts 2mm aluminium plate.

Main driving chain: The main chain imported from England, adopts heavy loading and high precision transmission chain with high tensile strangth and abrasive resistance. The intermittent device adopts parallel 3-cam indexing mechanism with precision length. The curve of cam is designed specially the can stroke angle is big to achieve smooth running. To ensure safety, the imported overload protector is added between the intermittent device and main driving chain.

Gripper bars: The gripper bars are made of high quality hard alloy aluminum, with the treatment of anode oxidation on the surface, which achieve a strong rigidity and slight weight, which guarantee a high precision paper sheet transmission under the high working speed.
