Help CenterIP65 Dynamic Industrial Trackball Vandal Proof With Washable Trackball Mouse
Related Products
-
2016 New IP68 Dynamic Washable Stainless Steel Optical Mouse TrackballUS$ 50 - 99MOQ: 1 Set -
Electroplated Black IP65 Static Stainless Steel Trackball MouseNegotiableMOQ: 1 Set
-
Customize Metal Trackball With Numeric KeypadNegotiableMOQ: 1 Piece
-
IP65 Dynamic Water Proof Red Phenolic Resin Mechanical Trackball MoudleNegotiableMOQ: 1 Set
-
Industrial Sealed Touchpad With Integrated Numeric KeypadNegotiableMOQ: 1 Set
Quick Details:
1. IP65 dynamic vandal proof stainless steel industrial optical trackball
2. 38.0mm optical trackball
3. IP68 dynamic optical trackball module with 800 DPI
4. Top panel mounting solution.
Descriptions:
1. IP65 dynamic rated vandal proof stainless steel optical trackball
2. IP68 dynamic rated washable 38.0mm hardened resin optical trackball module with +800 DPI resolutions for fast and
accurate fixing cursor position with extreme smooth operation without any noise
3. Three IP65 dynamic sealed and ruggedized stainless mouse buttons above trackball designed for right & left clicking and
scrolling up and down with ball rolling
4. Top metal ring can be movable for easy cleaning from top panel
5. Stainless steel top plate with threaded bolts for top panel mounting solution
MAIN FEATURE:
1. IP68 dynamic waterproof (from the top)
2. Solid State Optical Navigation Technology
3. Removable Ball Versions
4. Maintenance free with no moving parts
5. Intrinsically and ESD safe operation
6. Quadrature, PS/2 and USB outputs
7. Anti-vandal options
8. Output cables and switch input cables (option)
9. Decontamination Friendly
Applications:
This trackball is mainly targeted for use for:
A: unsupervised or semi -supervised positions of varied access applications,
B: internet terminals and information kiosks at universities,
C: shopping malls, hotels, airports, railway stations and other public areas,
D: ticket vending machines, gas stations, cash machines (ATMs), Internet public phones etc.
Specifications:
ITEM |
SPECIFICATION |
|
Mechanical |
Key |
3 keys, sealed stainless steel buttons |
Key top style |
sealed round stainless steel buttons with tactile feeling |
|
Front Plate |
Quality brushed SUS304 stainless steel |
|
Key Travel |
0.45mm |
|
Ball |
Epoxy Resin with special surface treatment, 38mm/1.50' |
|
Key switch lifespan |
more than 5 Mio actuations |
|
Track ball lifespan |
> 5 Mio revolutions |
|
Back Metal Cover |
Rear side integrated electronics protected by a metal cover |
|
Tracking Force |
20 grams Nominal Continuous Friction / Scraper Ring |
|
Dimension |
Dimensions with 38mm track ball, Front plate (LxW): 107.0mm x 120.0mm |
|
Interface |
PS2, USB are available, Y type cable with ports of PS2 and USB |
|
Electrical |
Power supply |
5V DC+ 10%, keyboard interface |
Protection level |
IP68 (front panel), NEMA4X, IK10 |
|
EMC Standard |
EN55022(B) |
|
Power consuming |
≤1.00W(dynamic) |
|
≤0.2W(static) | ||
Contact Material |
sealed stainless steel buttons |
|
Environmental |
Operating temperature |
-20ºC~+ 60º C |
Storage temperature |
- 30ºC~+ 70ºC |
|
Operating RH |
30~90% |
|
Atmospheric pressure |
60~106Kpa. |
|
Reliable |
Certificates |
RoHS compliant, CE and FCC certified. ESD |
MTBF |
>50000H |
|
MTTR |
< 30min |
|
OS |
OS is under All windows, Linux, Unix, Mac OS9 / OSX |
|
Packing Details |
Each unit to a suitable brown box, suitable brown boxes to a standard export carton. |
|
