Help CenterElectroplated Black IP65 Static Stainless Steel Trackball Mouse
Related Products
-
Customize Metal Trackball With Numeric KeypadNegotiableMOQ: 1 Piece -
IP65 Dynamic Water Proof Red Phenolic Resin Mechanical Trackball MoudleNegotiableMOQ: 1 Set
-
Industrial Sealed Touchpad With Integrated Numeric KeypadNegotiableMOQ: 1 Set
-
IP65 Ruggedized Touchpad With Integrated Water Proof KeypadNegotiableMOQ: 1 Set
-
38mm IP65 Mechanical Trackball ModuleNegotiableMOQ: 1 Set
Dimension:107.0mm x 120.0mm (top panel)
Description:38.0mm (1.5') vandal proof IP65 stainless steel mechanical trackball (laser trackball optional),super quality durable Black Titanium Electroplated on stainless steel housing, with top panel mounting solution.
MAIN FEATURE
Emulates most popular mice - uses existing mouse driver and mouse software Interfaces for most workstations and computers.
Super quality durable Black Titanium Electroplated on stainless steel housing.
All Metal Mechanicals provide for rugged, smooth, long lasting operation.
Available 40mm, 38mm, 25mm, 22mm, 19mm and 16mm Diameter Stainless steel or Hard Phenolic Resin Ball for smooth, durable operation and precise cursor positioning.
Rate Sensitive Dynamic Resolution provides for accelerated movement of the cursor when the ball is moved fast, while retaining one-pixel positioning accuracy when the ball is moved slowly.
Teflon Ball Shields are available for dirt and water protection in harsh environments.
TECHNICAL SPECIFICATION
ITEM |
SPECIFICATION |
|
Mechanical |
Key |
2 keys, quality brushed stainless steel |
Key top style |
Protuberant Rectangular Keys, |
|
Front Plate |
Quality brushed stainless steel |
|
Key Travel |
2.0mm |
|
Ball diameter |
38.1mm/1.50" (19mm, 25mm, 36mm 40mm also available) |
|
Key switch lifespan |
more than 10 Mio actuations |
|
Track ball lifespan |
> 10 Mio revolutions |
|
Back Metal Cover |
Rear side integrated electronics protected by a metal cover |
|
Actuation Force |
1.0N to 3.0N |
|
Mounting Rack |
Aluminum alloy |
|
Dimension |
Dimensions with 38mm track ball, Front plate (W x H): 107.0mm x 120.0mm |
|
Interface |
PS2, USB are available, Y type cable with ports of PS2 and USB |
|
Electrical |
Power supply |
5V DC+ 10%, keyboard interface |
Protection level |
IP65 (front panel), NEMA3 |
|
EMC Standard |
EN55022(B) |
|
Power consuming |
≤1.00W(dynamic) |
|
≤0.2W(static) | ||
Contact Material |
Gold/Carbon |
|
Environmental |
Operating temperature |
-20ºC~+ 60º C |
Storage temperature |
- 30ºC~+ 70ºC |
|
Operating RH |
30~90% |
|
Atmospheric pressure |
60~106Kpa. |
|
Reliable |
Certificates |
RoHS compliant, CE and FCC certified. |
MTBF |
>50000h |
|
MTTR |
< 30min |
|
OS |
OS is under DOS/Windows95/98/NT/ME/2000/XP/2003/Vista/Win7, Linux, Unix, Mac OS9 / OSX |
|
Packing Details |
Each unit to a suitable brown box, suitable brown boxes to a standard export carton. |
|
