MODEL NO.: K-TEK-M90-25-MTB
DESCRIPTION
IP65 dynamic Vandal proof Red Phenolic Resin Mechnical Trackball moudle with +400 DPI resolutions, stainless steel housing protects the trackball module, high quality durable Black Electroplate Titanium included.rear stainless steel panel mounted with 3 sealed polymer mouse buttons designed for right & left clicking and scrolling up and down with ball rolling,with rear panel mounting solution.
DIMENSIONS: 90.00mm x 105.00mm(top panel)
MAIN FEATURE
- Emulates most popular mice - uses existing mouse driver and mouse software Interfaces for most workstations and computers.
- All Metal Mechanicals provide for rugged, smooth, long lasting operation.
- Available 50mm, 40mm, 38mm, 25mm, 22mm, 19mm and 16mm diameter stainless steel or hard phenolic resin ball for smooth, durable operation and precise cursor positioning.
- Rate Sensitive Dynamic Resolution provides for accelerated movement of the cursor when the ball is moved fast, while retaining one-pixel positioning accuracy when the ball is moved slowly.
- Teflon Ball Shields are available for dirt and water protection in harsh environments.
TECHNICAL SPECIFICATION:
ITEM |
SPECIFICATION |
|
Mechanical |
Key |
3 keys, quality brushed stainless steel |
Key top style |
Non-protuberant rectangular Keys, |
|
Front Plate |
Quality brushed stainless steel |
|
Key Travel |
0.45mm |
|
Ball diameter |
25.4mm/1.0' (19mm, 25mm, 36mm 40mm, 50mm also available) |
|
Key switch lifespan |
more than 5 Mio actuations |
|
Track ball lifespan |
> 10 Mio revolutions |
|
Back Metal Cover |
Rear side integrated electronics protected by a metal cover |
|
Actuation Force |
1.0N to 3.0N |
|
Mounting Rack |
Stainless steel |
|
Dimension |
Dimensions with 25mm track ball, Front plate (W x H): 65.0 x 80.0mm, Overall (W x H x D): 90.0 x 90.0 x 29.5mm |
|
Interface |
PS2, USB are available, Y type cable with ports of PS2 and USB |
|
Electrical |
Power supply |
5V DC+ 10%, keyboard interface |
Protection level |
IP65 (dynamic), NEMA3 |
|
EMC Standard |
EN55022(B) |
|
Power consuming |
≤1.00W(dynamic) |
|
≤0.2W(static) | ||
Contact Material |
Gold-on-Gold |
|
Environmental |
Operating temperature |
-20ºC~+ 60º C |
Storage temperature |
- 30ºC~+ 70ºC |
|
Operating RH |
30~90% |
|
Atmospheric pressure |
60~106Kpa. |
|
Reliable |
Certificates |
RoHS compliant, CE and FCC certified. ESD |
MTBF |
>50000h |
|
MTTR |
< 30min |
|
OS |
OS is under All windows, Linux, Unix, Mac OS9 / OSX |
|
Packing Details |
Each unit to a suitable brown box, suitable brown boxes to a standard export carton. |
|
