Help Center38mm IP68 Optical Trackball / Vandal Proof Trackball / Water Proof Trackball
Related Products
-
Rear Panel Mounting Vandal Proof 25mm Metal Trackball IndustrialNegotiableMOQ: 1 Set -
25mm Vandal Proof Stainless Steel Optical TrackballNegotiableMOQ: 1 Set
-
Customize Metal Trackball With Numeric KeypadNegotiableMOQ: 1 Piece
-
38mm IP65 Stainless Steel Optical Trackball ModuleNegotiableMOQ: 1 Set
-
IP68 Rated Washable 16mm Stainless Steel Optical Trackball MouseNegotiableMOQ: 1 Set
Specifications
1.38.0mm (1.5') vandal proof IP68 dynamic waterproof optical trackball module2.variable friction ring
3.3 mouse keys
38.0mm (1.5') vandal proof IP68 dynamic waterproof optical trackball module with variable friction ring and 3 mouse keys, with top panel mounting solution.
MAIN FEATURE
- IP68 dynamic waterproof (from the top)
- Solid State Optical Navigation Technology
- Ball tracking force can be set from loose (10 grams) to high (120 grams) in 4 steps; ball can be removed.
- Maintenance free with no moving parts
- Intrinsically and ESD safe operation
- Retro-fittable into most existing OEM designs
- Quadrature, PS/2 and USB outputs
- Anti-vandal options
- Output cables and switch input cables (option)
- Decontamination Friendly
TECHNICAL SPECIFICATION:
ITEM |
SPECIFICATION |
|
Mechanical |
Key |
3 keys, quality brushed stainless steel |
Key top style |
Plain/Non-Protuberant rectangular keys |
|
Front Plate |
Quality brushed stainless steel |
|
Key Travel |
2.0mm |
|
Ball |
Epoxy Resin, 38mm/1.50' |
|
Key switch lifespan |
more than 10 Mio actuations |
|
Track ball lifespan |
> 10 Mio revolutions |
|
Back Metal Cover |
Rear side integrated electronics protected by a metal cover |
|
Tracking Force |
5 - 200 grams Nominal Continuous Variable Friction Ring/Removable Ball |
|
Dimension |
Dimensions with 38mm track ball, Front plate (W x H): 107.0mm x 120.0mm |
|
Interface |
PS2, USB are available, Y type cable with ports of PS2 and USB |
|
Electrical |
Power supply |
5V DC+ 10%, keyboard interface |
Protection level |
IP68 (front panel), NEMA3 |
|
EMC Standard |
EN55022(B) |
|
Power consuming |
≤1.00W(dynamic) |
|
≤0.2W(static) | ||
Contact Material |
Gold/Gold |
|
Environmental |
Operating temperature |
-20ºC~+ 60º C |
Storage temperature |
- 30ºC~+ 70ºC |
|
Operating RH |
3090% |
|
Atmospheric pressure |
60106Kpa. |
|
Reliable |
Certificates |
RoHS compliant, CE and FCC certified. |
MTBF |
>50000h |
|
MTTR |
< 30min |
|
OS |
OS is under DOS/Windows95/98/NT/ME/2000/XP/2003/Vista, Linux, Unix, Mac OS9 / OSX |
|
Packing Details |
Each unit to a suitable brown box, suitable brown boxes to a standard export carton. |
|
