Help CenterIP65 Vandal Resistant 38mm Wired Kiosk Stainless Steel Trackball Mouse
Related Products
-
38mm IP68 Optical Trackball / Vandal Proof Trackball / Water Proof TrackballNegotiableMOQ: 1 Set -
Rear Panel Mounting Vandal Proof 25mm Metal Trackball IndustrialNegotiableMOQ: 1 Set
-
25mm Vandal Proof Stainless Steel Optical TrackballNegotiableMOQ: 1 Set
-
Customize Metal Trackball With Numeric KeypadNegotiableMOQ: 1 Piece
-
38mm IP65 Stainless Steel Optical Trackball ModuleNegotiableMOQ: 1 Set
Part number: K-TEK-A107-38-LTB
DESCRIPTION
IP65 dynamic rated vandal resistant stainless steel laser trackball with IP65 dynamic sealed & ruggedized stainless mouse buttons and IP68 dynamic rated washable 38.0mm stainless steel laser trackball module with +1200 DPI resolutions for fast and accurate fixing cursor position with extreme smooth operation without any noise, optical trackball module protected and shielded by stainless steel housing, 3 sealed stainless steel mouse buttons designed for right & left clicking and scrolling up and down with ball rolling, stainless steel top plate with threaded bolts for top panel mounting solution.
MAIN FEATURE
- Emulates most popular mice - uses existing mouse driver and mouse software Interfaces for most workstations and computers.
- All Metal Mechanicals provide for rugged, smooth, long lasting operation.
- Available 40mm, 38mm, 25mm, 22mm, 19mm and 16mm Diameter Stainless steel or Hard Phenolic Resin Ball for smooth, durable operation and precise cursor positioning.
- Rate Sensitive Dynamic Resolution provides for accelerated movement of the cursor when the ball is moved fast, while retaining one-pixel positioning accuracy when the ball is moved slowly.
- Teflon Ball Shields are available for dirt and water protection in harsh environments.
TECHNICAL SPECIFICATION
ITEM |
SPECIFICATION |
|
Mechanical |
Key |
2 keys, quality brushed stainless steel |
Key top style |
Protuberant Rectangular Keys, |
|
Front Plate |
Quality brushed stainless steel |
|
Key Travel |
2.0mm |
|
Ball diameter |
38.1mm/1.50" (19mm, 25mm, 36mm 40mm also available) |
|
Key switch lifespan |
more than 10 Mio actuations |
|
Track ball lifespan |
> 10 Mio revolutions |
|
Back Metal Cover |
Rear side integrated electronics protected by a metal cover |
|
Actuation Force |
1.0N to 3.0N |
|
Mounting Rack |
Aluminum alloy |
|
Dimension |
Dimensions with 38mm track ball, Front plate (W x H): 107.0mm x 120.0mm |
|
Interface |
PS2, USB are available, Y type cable with ports of PS2 and USB |
|
Electrical |
Power supply |
5V DC+ 10%, keyboard interface |
Protection level |
IP65 (front panel), NEMA3 |
|
EMC Standard |
EN55022(B) |
|
Power consuming |
≤1.00W(dynamic) |
|
≤0.2W(static) | ||
Contact Material |
Gold/Carbon |
|
Environmental |
Operating temperature |
-20ºC~+ 60º C |
Storage temperature |
- 30ºC~+ 70ºC |
|
Operating RH |
30~90% |
|
Atmospheric pressure |
60~106Kpa. |
|
Reliable |
Certificates |
RoHS compliant, CE and FCC certified. |
MTBF |
>50000h |
|
MTTR |
< 30min |
|
OS |
OS is under DOS/Windows95/98/NT/ME/2000/XP/2003/Vista,WIN7, Linux, Unix, Mac OS9 / OSX |
|
Packing Details |
Each unit to a suitable brown box, suitable brown boxes to a standard export carton. |
|
