IP65 Waterproof Desktop Industrial Usb 38mm Metal Trackball Controller for pc
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
KEY-TEK
Model Number:
K-TEK-A107-38-TB-DT
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
IP65 Vandal Resistant 38mm Wired Kiosk Stainless Steel Trackball MouseNegotiableMOQ: 1 Set -
38mm IP68 Optical Trackball / Vandal Proof Trackball / Water Proof TrackballNegotiableMOQ: 1 Set
-
Rear Panel Mounting Vandal Proof 25mm Metal Trackball IndustrialNegotiableMOQ: 1 Set
-
25mm Vandal Proof Stainless Steel Optical TrackballNegotiableMOQ: 1 Set
-
Customize Metal Trackball With Numeric KeypadNegotiableMOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
KEY-TEK
Model Number
K-TEK-A107-38-TB-DT
Part number: K-TEK-A107-38-TB-DT
Dimensions: 107.0mm x 120.0mm x 44.0mm (L x W x H)
DESCRIPTION
IP65 dynamic rated Vandal proof Stainless Steel industrial Trackball with dynamic rated washable 38.0mm stainless steel trackball module with 400/800/1200 DPI resolutions for fast and accurate fixing cursor position with extreme smooth operation without any noise, trackball module protected and shielded by stainless steel housing, with movable stand alone desktop version or mountable stand alone desktop versions with stainless steel housing.
MAIN FEATURE
- Emulates most popular mice - uses existing mouse driver and mouse software Interfaces for most workstations and computers.
- All Metal Mechanicals provide for rugged, smooth, long lasting operation.
- Available 40mm, 38mm, 25mm, 22mm, 19mm and 16mm Diameter Stainless steel or Hard Phenolic Resin Ball for smooth, durable operation and precise cursor positioning.
- Rate Sensitive Dynamic Resolution provides for accelerated movement of the cursor when the ball is moved fast, while retaining one-pixel positioning accuracy when the ball is moved slowly.
- Teflon Ball Shields are available for dirt and water protection in harsh environments.
TECHNICAL SPECIFICATION
| ITEM | SPECIFICATION | |
| Mechanical | Key | 2 keys, quality brushed stainless steel |
| Key top style | Protuberant Rectangular Keys, | |
| Front Plate | Quality brushed stainless steel | |
| Key Travel | 2.0mm | |
| Ball diameter | 38.1mm/1.50" (19mm, 25mm, 36mm 40mm also available) | |
| Key switch lifespan | more than 10 Mio actuations | |
| Track ball lifespan | > 5 Mio revolutions | |
| Back Metal Cover | Rear side integrated electronics protected by a metal cover | |
| Actuation Force | 1.0N to 2.0N | |
| Mounting Rack | Aluminum alloy | |
| Dimension | 38mm track ball, 107.0mm x 120.0mm x 32.0mm (L x W x H) | |
| Interface | PS2, USB are available, Y type cable with ports of PS2 and USB | |
| Electrical | Power supply | 5V DC+ 10%, keyboard interface |
| Protection level | IP65 (front panel), NEMA3 | |
| EMC Standard | EN55022(B) | |
| Power consuming | ≤1.00W(dynamic) | |
| ≤0.2W(static) | ||
| Contact Material | Gold/Carbon | |
| Environmental | Operating temperature | -20ºC~+ 60º C |
| Storage temperature | - 30ºC~+ 70ºC | |
| Operating RH | 3090% | |
| Atmospheric pressure | 60106Kpa. | |
| Reliable | Certificates | RoHS compliant, CE and FCC certified. |
| MTBF | >20000h | |
| MTTR | < 30min | |
| OS | OS is under DOS/Windows95/98/NT/ME/2000/XP/2003/Vista, Linux, Unix, Mac OS9 / OSX | |
| Packing Details | Each unit to a suitable brown box, suitable brown boxes to a standard export carton. | |
