Top Panel Mounting Metal Optical Trackball With 3 Buttons

Name: Top Panel Mounting Metal Optical Trackball With 3 Buttons
Brand: IKB-MKB
SKU: 116013081

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

IKB-MKB

Model Number:

K-TEK-B107F-38-OTB

Key Technology (China) Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shen Zhen and HK

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name IKB-MKB

Model Number K-TEK-B107F-38-OTB

38.0mm (1.5') vandal proof IP68 dynamic waterproof optical trackball with 3 mouse keys, with top panel mounting solution.

MAIN FEATURE

TECHNICAL SPECIFICATION:

ITEM		SPECIFICATION
Mechanical	Key	3 keys, quality brushed stainless steel
	Key top style	Plain/Non-Protuberant rectangular keys
	Front Plate	Quality brushed stainless steel
	Key Travel	2.0mm
	Ball	Epoxy Resin, 38mm/1.50'
	Key switch lifespan	more than 10 Mio actuations
	Track ball lifespan	> 10 Mio revolutions
	Back Metal Cover	Rear side integrated electronics protected by a metal cover
	Tracking Force	20 grams Nominal Continuous Friction / Scraper Ring
	Dimension	Dimensions with 38mm track ball, Front plate (W x H): 107.0mm x 120.0mm
Interface	PS2, USB are available, Y type cable with ports of PS2 and USB
Electrical	Power supply	5V DC+ 10%, keyboard interface
	Protection level	IP68 (front panel), NEMA3
	EMC Standard	EN55022(B)
	Power consuming	≤1.00W(dynamic)
	Power consuming	≤0.2W(static)
	Contact Material	Gold/Gold
Environmental	Operating temperature	-20ºC~+ 60º C
	Storage temperature	- 30ºC~+ 70ºC
	Operating RH	3090%
	Atmospheric pressure	60106Kpa.
Reliable	Certificates	RoHS compliant, CE and FCC certified.
	MTBF	>50000h
	MTTR	< 30min
OS	OS is under DOS/Windows95/98/NT/ME/2000/XP/2003/Vista, Linux, Unix, Mac OS9 / OSX
Packing Details	Each unit to a suitable brown box, suitable brown boxes to a standard export carton.
