LOW Price High quality Used LB 1500 DRUM asphalt mix plant

Specifications

1.Drum Mix Asphalt Plant

2. mechanical transmission, low failure rate, easy to repair.

3.excellent performance, reasonable price

  LOW Price High quality Used LB 1500 DRUM asphalt mix plant

  Main technical parameters of asphalt drum mix equipment

Type                                                            LB1500                  LB2000                    LB2500                   LB3000                 LB4000

Rated production                                       120t/h                     160 t/h                      200 t/h                     240 t/h                  320 t/h

Dry cylinder                                            1.8  m×7m                 2.2m×8m                 2.35m×9m           2.5m×10m           2.8m×11m

Bag dust-remover                                   CNM476                  CNM654                    CNM832               CNM1012               CNM1308

mission standard                                   50mg/nm              350mg/nm                350mg/nm            350mg/nm           350mg/nm3

Vibrating screen                                      4 layers                 5 layers                       5 layers                      5 layers                5 layers

Mixing kettle capacity                              1500kg                  2000kg                        2500kg                      3000kg                4000kg

Mixing cycle                                                 45s                        45s                                45s                            45s                      45s

Asphalt tank volume                               50000L              2×50000L                    2×50000L                  3×50000L          4×50000L

Heat conduction oil stove               300,000 k col/h    500,000 k col/h        500,000 k col/h          800,000 k col/h      1,000,000 k col

End-product container volume               90t                        110t                              110t                               200t                     200t

Control system                                                                                    Manual /semi-auto / automatic

Weighing accuracyAggregate           ≤±0.4%                  ≤±0.4%                         ≤±0.4%                       ≤±0.4%                  ≤±0.4%

Powder material                                  ≤±0.3%                  ≤±0.3%                         ≤±0.3%                       ≤±0.3%                  ≤±0.3%

Asphalt                                                  ≤±0.2%                  ≤±0.2%                         ≤±0.2%                       ≤±0.2%                  ≤±0.2%

Installed general power                   320kw                      400kw                           530kw                          720kw                    820kw

Main Structure of asphalt drum mix plants :

Asphalt drum mix plants mainly includes batching systems, drying systems, burning systems, hot material enhance, vibrating screen, hot material storage bins, weighing mixing system, asphalt supply system, powder supply system, dust removal system, finished product storage bin,control system and other parts.

nude cargo or based on customer's requirement.

1.Wire cables are used for fastening the machine on the trailer or inside the container.

2.Cork wood are placed in front or behind the machine to protect it.

3.Plastic film is covered on the machine as a rain-roof.

Haomei machinery equipment co.,Ltd is located in the famous machinery capital of Zhengzhou, China. We are professional machinery products manufacturer-featuring a wide range of quality  asphalt mixing plant,  concrete mixer, concrete batching plant, mobile concrete plant, concrete pump, truck pump with boom, truck mixer, etc. We adhere to the policy of "QUALITY FIRST AND INTEGRITY WINS" to cooperate with clients from all over the world. Our company covers over 100 acres with workshop area of more than 50,000 square meters has 5 branches.

Certificates and customers

1. Why dose the customs choose our HAOMEI concrete mixer?

Specialize on manufacturing only asphalt mixing plant

Commitment used to serve clients as their solution partner.

What's the quality of your concrete mixer?

Rest assured that our products have got ISO, CE certificated. We have the professional team for the products' study and development.

What’s more, LDX200Asphalt mixing plant is on sale with a competitive price and I believe you will not miss this chance. We sincerely hope we can establish business relationship between us and welcome you visit our factory.

2. When do you deliver the goods?

less than 30 days after the deposit.
