A new technology with higher quality lower cost foam asphalt warm mix technique asphalt mix plant
LB series of asphalt concrete mixing plant is my company to absorb advanced technology at home and abroad, integrated the characteristics of various models at home and abroad, combined with the company for many years production experience the development of high-end new products.The product was for building urban and rural roads, highways, large airports and other projects.
LB asphalt concrete mixing equipment production capacity of 60-320 tons/hour, the whole machine high degree of automation, accurate measurement, high reliability, is an ideal equipment, high-grade highway construction and maintenance of asphalt concrete mixing equipment is my company introduction of international advanced technology and combining with the domestic highway points and research and development of new products.Burner of its key components, adopt international first-line brand components such as sensor control system controlled by programmable controller and computer, to the production process of weighing, mixing, feeding for automatic and manual control, such as mixer lining board, blade with high wear-resistant alloy castings, mixing arm with alloy cast steel, long service life;Aggregate using cumulative dose, powder and asphalt adopt separate metering, accuracy and reliability of the card with material;Hot aggregate, kuangfen adopts double chain bucket elevator, and has the automatic tensioning device.Combustion system has: light oil/oil/coal burner.Dust removal system with gravity dust removal, cyclone dust removal and water dust, bag dust removal;Finished product bin has set type and the type (30, 60, 80, 100, 80, 100 tonnes) combination in the form for the user to choose from
LB series of asphalt concrete mixing plant main technical parameter table
Parameters models LB1000 LB1500 LB2000 LB3000 LB 4000
Aggregate measurement accuracy (%) ± 0.5 ±0.5 ±0.5 ±0.5 ± 0.5
Powder measuring accuracy (%) ±0.3 ±0.3 ±0.3 ±0.3 ±0.3
Asphalt measuring accuracy (%) ±0.2 ±0.2 ±0.2 ±0.2 ±0.2
Production (t/h, water content of 5% or less) 60-80. 90-120 120-160. 160-180. 180-260.
Finished product temperature (° C) 140-180 140-180 140-180 140-180 140-180
The finished product oil stone ratio (%) 3 - 7 3 - 7 3 - 7 3 - 7 3 - 7
Installed total power (Kw) 260 350 490 720 830
Machine type modules can be demolition type
Fuel (optional) Diesel, standards, heavy oil and coal
Operation control mode PC + PLC control, full automatic, semi-automatic and manual control modes of three
Warm mix asphalt technology
In temperature mixing technology, we use the foam asphalt warm mix technique does not produce chemical reaction, reduce the production cost, construction period, and will not result in asphalt mixture performance advantages, such as by highway industry both at home and abroad.Bubble drain temperature mixing method, refers to the normal hot mix asphalt mixture production process, adding a certain proportion of water in high temperature of asphalt, asphalt sharply vaporization, rapid expansion volume, generate foam asphalt.Asphalt is added into the mixing cylinder in the form of foam asphalt and aggregate mixing into asphalt mixture, foam asphalt asphalt physical properties compared to temporarily change, show the asphalt viscosity decreased significantly, improve the construction of the asphalt mixture workability, so that the mixture at a relatively low temperature, mixing, paving and rolling can be performed.
relevant case
In the domestic high-speed road, 70 # asphalt modified with laying 137.5 pxAC - 20 in asphalt mixture on the surface, the production formula 0 ~ 20%, 18% for 3 ~ 6 mm, 3 mm 6 ~ 11 mm 20%, 11 ~ 18 mm 22%, 18 ~ 25 mm 15% 15%, powder 5%, asphalt, 26 s mixing time, discharge temperature about 150 ℃, the production, after mixing in discharging and paving almost can't see the blue smoke, performance and was equal to that of hot mix asphalt mixture.
addition
Hao mei machinery will be adapted to provide customers with solutions, to minimize customer costs, and our this behavior is embodied in all aspects of the product.
In order to achieve high efficiency of heat exchange efficiency, truly for the customer in use, save every overhead, hao beauty machine in the equipment structure design, the drying drum feed blade structure optimization design, a full set of equipment using negative pressure structure, mining with efficient drying burner fuel atomization control precision and accurate intelligent oil distribution technology, for a whole set of hot asphalt mixing station system to provide the powerful heat exchange efficiency, fuel consumption of asphalt mixing plant produce a direct impact on performance
At the same time, our equipment more durable, our company is Sweden ABBRUZAHOLMSBRUK mixing parts production of wear resistant castings, can satisfy the requirement of special high wear resistance and environment of super wear resistance, and engineering mixer industry enjoys a high reputation in Europe.
Pre-sale service
Suggest the best suitable products for customers according to their requirement, with sincere attitude
Try our best to Offer the technical service before installment.
Give our customers training for main problems and solution, maintenance and so on
During sale service
Supervising the whole process of producing and shipment and making sure our product deliver with good condition in time.
Offer all the necessary technical data to customer.
After sale service
Offer installment, debugging, and repairing service after customer receiving our products.
Offer work-site training.
Solve the customer’s complain at first time and try to arrive at the work site once get your notice.
We record every sold product on installment, debugging, and repairing situation. And provide professional maintenance advice.
We will visit customer timely to learn customer’s advice and new demand
Haomei machinery equipment co.,Ltd is located in the famous machinery capital of Zhengzhou, China. We are professional machinery products manufacturer-featuring a wide range of quality asphalt mixing plant, concrete mixer, concrete batching plant, mobile concrete plant, concrete pump, truck pump with boom, truck mixer, etc. We adhere to the policy of "QUALITY FIRST AND INTEGRITY WINS" to cooperate with clients from all over the world. Our company covers over 100 acres with workshop area of more than 50,000 square meters has 5 branches.
Certificates and customers
1. Why dose the customs choose our HAOMEI concrete mixer?
Specialize on manufacturing only asphalt mixing plant
Commitment used to serve clients as their solution partner.
What's the quality of your concrete mixer?
Rest assured that our products have got ISO, CE certificated. We have the professional team for the products' study and development.
What’s more, LDX200Asphalt mixing plant is on sale with a competitive price and I believe you will not miss this chance. We sincerely hope we can establish business relationship between us and welcome you visit our factory.
2. When do you deliver the goods?
less than 30 days after the deposit.
