sensitive ozone analyzer CL7685 ozone purifier machine/on-line measuring equipment/online ozone detector
Product feature:
Functional Specifications:
Input The instrument accepts input from potentiostatic sensor for Active Chlorine, Chlorine Dioxide and D.Ozone measuring. A second input is provided for 3 wires Pt100 Temperature sensor. Temperature compensation The unit is supplied with manual or automatic Temperature compensation and Temperature information may be displayed on LCD. The instrument detects the absence or malfunctioning of the Temperature sensor and automatically switches to manual operation mode. Measuring ranges The unit provides an input range which may be selected from 0/1.999 or 0/19.99 PPM. Auto ranging function may be activated for the measuring range 0/1.999 PPM. Auto ranging allows the operator to calibrate the unit in the low range, against a high concentration of standard solution.
Alarm Reley:
The unit contains a SPST relay designated as an alarm relay.
Cleaning Function:
The unit contains a SPST relay designed for the auto clean cycle. It's possible manually activate the cleaner to test its operation. The operator can change the frequency of cleaning. The configuration routine selects: - auto/manual operation - the cleaning time - the holding time.
Integrated ozone concentration sensor structure:
This paragraph ozone concentration sensor and display by the host header of two parts, the structure as shown below:
1 Ozone gas out of the air intake (gas inlet, outlet diameter 4mm, diameter 6mm.)
2 Ozone gas out of the air intake (gas inlet, outlet diameter 4mm, diameter 6mm.)
3 Power and signal input and output terminals
Its power and signal input and output terminals are defined as follows:
Needle angle |
1 |
2 |
input |
24V+ |
24V- |
|
White |
Black |
Needle angle |
3 |
4 |
5 |
6 |
7 |
8 |
9 |
10 |
output |
5V+ |
5V- |
485+ |
485- |
Zeroing |
Zeroing |
4-20mA+ |
4-20mA- |
|
Brown |
Red |
Orange |
Yellow |
Green |
Blue |
Purple |
Gray |
Ozone sensor display header:
1.485 display header 2. Signal input terminals
3.front panel 4. Display window
5.Zeroing button 6.Zeroing button
The signal input terminals are defined as follows:
Needle angle |
1 |
2 |
3 |
4 |
5 |
6 |
input |
5V+ |
5V- |
485+ |
485- |
Zeroing |
Zeroing |
|
Brown |
Red |
Orange |
Yellow |
Green |
Blue |
Application Scope:
Certificate:
Our company has obtained CE, FC and FCC certificate.
Payment:
Paypal, Visa and L/C and T/T are all accepted.
After-Sales Service:
1.We provide 12month free maintenance.
2.The buyer should return the product in the original conditions to us and should bear the shipping cost for return.
3. If any part is required to be replaced, the buyer should also pay for the costs of the parts to be replaced.
Workshop:
Equipment Field:
Company Profile
Shenzhen Long Life O3 Tech Co. Ltd is a high-tech company based on the advanced ozone technology.
Over the past 15 years, Shenzhen Long Life has worked on the research & design, manufacturing of ozone generators which vastly use on drinking water purification, sewage treatment plant (STP), and waste gas treatment, swimming pool, food procession and etc.
After many years of constant efforts, Shenzhen Long Life has achieved great success on the product design, accessories design and development.
Regarding the product quality, we strictly comply with the process of QC (quality control); Such as: IQC (incoming Quality Control), IPQC (Input processing quality control), OQC (outgoing quality control) and QA (quality assurance)
We adopt OEM or ODM for the different requirements of the partners. Now, there are many partners locate in the many countries.
