Wire and cable can be customized
Application
The product can be fixedly laid in places where cable can be protected from foreign mechanical force up to a certain degree, such as indoor, underground, cable conduit or tunnel for power transmission and distribution line project, with rated A/C Uo/U being 0.6/1KV or below.
Standard
GB/T 12706.1, IEC 60502-1
Technical Data
Conductor: Plain copper conductor to GB/T 3956(Class 1 or 2)
Insulation: XLPE (Cross-linked Polyethylene)
Armour: Steel Tape
Sheath: PVC (Polyvinyl Chloride) type PVC/ST1
Sheath Color: Black
Temperature Rating: 0°C to +90°C
Core Identification: Color coded
Technical name YJV22 CABLE
Type |
Name |
Main Application |
|
Cu Core |
Al Core |
||
YJV |
YJLV |
XLPE insulated,PVC or PE Sheathed Power Cable |
For laying indoor,tunnel,channel and undergroud,Unable to bear external mechanical force,but bear the traction force during laid |
YJV22 |
YJLV22 |
XLPE Insulated,Steel Tape Armoured,PVC or PE Sheathed Power Cable |
For laying indoor,tunnel,channel and undergroud Able to bear external mechanical force,but unable to bear large pulling force |
YJV32 |
YJLV32 |
XLPE Insulated,Fine Steel Wire Armoured,PVC or PE Sheathed Power Cable |
For laying in shaft with large difference of level.Able to bear external machanical force and maderate pulling force |
YJV42 |
YJLV42 |
XLPE Insulated,Thick Steel Wire Armoured,PVC or PE Sheathed Power Cable |
Able to bear positive pressure and pulling force |
