Superfine Powder Ball Crusher Ball Mill Grinding Mill

Superfine Powder Ball Crusher Ball Mill Grinding Mill thumbnail-1
Superfine Powder Ball Crusher Ball Mill Grinding Mill photo-1
US$ 2,800 - 180,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Ball Mill
Motor Type:
AC Motor
Contact Supplier Request Quote Chat Now
Henan Teng Fei Machine Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Lianyungang
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Ball Mill
Motor Type AC Motor
Power(W) 18.5-475 kw
Capacity(t/h) 0.65-29 t/h
Place of Origin Henan, China
Brand Name TengFei
Model Number 900x3000
Dimension(L*W*H) 5340x2940x3650mm
Weight 4.6 t
Certification ISO ,CE
Warranty 12 Months
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Ball Mill Grinding
1. Simple structure
2. Low operating cost
3. Low power consumption
4. Whole base support

Ball Mill Grinding Mill



 Product Description

Ball Mill Grinding Mill Application:

Ball Mill is the key equipment for grinding after the crushing process, and it is widely used in the manufacture industries, such as aluminium, calcite, cement, silicate, new building material, refractory material, fertilizer, ferrous metal, nonferrous metal and glass ceramics, it also can be used for the dry and wet grinding for all kinds of ores and other grind-able materials.

Superfine Powder Ball Crusher Ball Mill Grinding Mill



The Ball Mill is horizontal cylindrical rotation device, driven by brim gearwheel. There are two chambers and grid. Material goes into the first chamber through the feeding inlet. Inside the first chamber, there are stage liners and ripple liners as well as steel balls. The shell rotates so as to generate electricity, and this force brings ball to a certain height and then balls drop down by gravity, the impact is the grinding force to the material. After the primary grinding, materials go into the second chamber through segregate screen. In the second chamber, there are flat liners and steel ball. After the secondary grinding, material is discharged from the discharging mouth.Then the whole grinding process is ended.

Superfine Powder Ball Crusher Ball Mill Grinding Mill



Structure of Ball Mill Grinding Mill :
The machine is composed of feeding part, discharging part, turning part and driving part (reducer, small driving gear, electric motor and electric control). The quill shaft adopts cast steel part and the liner is detachable. The turning gearwheel adopts casting hobbing process and the drum is equipped with wear-resistant liner, which has good wear-resistance. The machine is with stable and reliable working condition. Moreover, according to different materials and discharging methods, there are dry ball mills and wet ball mills for choice.

Superfine Powder Ball Crusher Ball Mill Grinding Mill



Superfine Powder Ball Crusher Ball Mill Grinding Mill



Ball Mill Grinding Mill Specification:



Model

Speed of bucket

(r/min)

Weight of

ball (t)

Feeding size

(mm)

Outputing size (mm)

Production    (t/h)

Power (kw)

Weight (t)

900×1800

42

1.4

≤20

0.075-0.89

0.65-2

18.5

3.6

900×3000

41

2.5

≤20

0.075-0.89

1.1-3.5

22

4.5

1200×2400

36

3.5

≤25

0.075-0.6

1.5-4.8

30

11.5

1200×3000

32

5

≤25

0.075-0.4

1.6-5

45

12.8

1200×4500

32

5.5

≤25

0.075-0.4

1.6-5.8

55

13.8

1500×3000

31

6.8

≤25

0.075-0.4

2-7

75

17

1500×4500

27

10.5

≤25

0.075-0.4

3.5--8

110

21

1500×5700

27

15

≤25

0.075-0.4

3.5-10

132

24.7

1830×3000

26

13

≤25

0.075-0.4

4-12

160

28

1830×6400

26

23

≤25

0.075-0.4

6.5-15

210

34

1830×7000

26

25

≤25

0.075-0.4

6.5-22

210

36

2200×5500

21

30

≤25

0.075-0.4

10-22

370

48.5

2200×6500

21

30

≤25

0.075-0.4

14-50

380

52.8

2200×7500

21

33

≤25

0.075-0.4

16-50

380

56

2200×9500

21

38

≤25

0.074-0.4

18-60

475

62



Ball Mill is the key equipment for grinding after the crush process, and it is widely used in the manufacture industries, such as aluminium, calcite, gold, silicon manganese stone ,phosphate ore, cement, silicate, new building material, refractory material, fertilizer, ferrous metal, nonferrous metal and glass ceramics, it also can be used for the dry and wet grinding for all kinds of ores and other grind-able materials.

Superfine Powder Ball Crusher Ball Mill Grinding Mill



Superfine Powder Ball Crusher Ball Mill Grinding Mill




Sharp tools make good work:

Tengfei has brought advanced manfacturing equipments from home & abroad. Numerical control machine tools with high-precision, large processing equipments & special test equipments provide strong safeguard for product quality and company development.

Superfine Powder Ball Crusher Ball Mill Grinding Mill





If you want to know more information about our product ,don't hesitate to contat on us through the below way
