Specifications
1)HDPE cellular2)Thickness:1mm.1.2mm.1.5mm.2mm
Height:50mm.100mm.150mm.200mm
3)powerful lateral confinement &rigidity
HDPE cellular
Introduction:
HDPE cellular is a net-shaped cell structure made by welding high intensity thermoplastic sheet. It is flexible and folded during transportation, stretching out and being filled with stone or concrete during service, and forming into structure with powerful lateral confinement and rigidity
Functions
1.HDPE cellular can be used as cushion coat to strengthen loading capacity of weak ground
2.HDPE cellular can paved in slope as slope protection structure.
3. HDPE cellular can be used to build the support block structure
aaaa
Performance parameter ofHDPE cellular
|
Item Model |
Tensile yield strength of the cell (MPa) |
Tensile strength at the welding joint (N/cm) |
Tensile strength at the joint of cell group Middle place (N/cm) |
Tensile strength at the joint of cell group edge |
||||
Material is PP |
Material is PE |
Material is PP |
Material is PE |
Material is PP |
Material is PE |
Material is PP |
Material is PE |
|
TGLG-50-400 |
≥23.0 |
≥20.0 |
≥100 |
≥100 |
≥120 |
≥120 |
≥200 |
≥200 |
TGLG-100-400 | ||||||||
TGLG-150-400 | ||||||||
TGLG-200-400 | ||||||||
