Plastic bottle blowing machine/ Semi-automatic bottle blow moulding machine/ PET bottle making machine Quality Choice

FOB Price

USD $5,000 - $10,000 / Set

1 Set(Min.Order)

Supply Ability 30 Set / Sets per Month
Port Shanghai Port
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Application:	Bottle	Plastic Processed:	PET
Blow Moulding Type:	Stretch Blow Moulding	Automatic:	Yes	Place of Origin:	Jiangsu, China
Brand Name:	hyford	Model Number:	HF	Voltage:	220v/380v
Power(W):	10kw	Dimension(LWH):	1.6T	Weight:	15565170cm
Certification:	CE,ISO,SGS	Warranty:	One year for free	After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

Plastic bottle blowing machine/ Semi-automatic bottle blow moulding machine/ PET bottle making machine

Product Description

Plastic bottle blowing machine/ Semi-automatic bottle blow moulding machine/ PET bottle making machine is suitable for producing PET/PE and PP plastic containers and bottles in all shapes. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle and hot fill bottle etc.

Main Features

1)High safety. high speed with high efficiency.

2)Manual saving, one man is enough for operation the machine.

3)Stable performing with easy maintaining.

4)Imported PLC controlling and man-machine interface computer.

5)Japan Omron inspection sensor.

6)Adopt the new type double bend arm and the four rod-clamping structure(won the patent): Cross direction; Middle mould board is move parallel; the distance between two mold board is adjusted by the chain wheel. Thus, the clamping force is very strong.

7)Power saving design that can increase your profits.

8)Segregate type air controlling system, which is designed for avoiding waste pollution.

9)Perfet after-sale service. We can offer you spare parts for free at the first year.

Detailed Pictures

Main Parameters

General Information	HF-1 one machine and one heater	HF-2 two machines and one heater
Clamping Force	10T
Clamping Stroke	160mm
Max. Stretching Stroke	360mm
Number of Cavities	2 Cavity	2 Cavity 2Pcs
Theoretical Output	0.01-1.5L:660-880BPH	0.01-1.5L:1000-1600BPH
Max .Mould Thickness	220mm
Mould plate size	470x350m
Voltage Standard	380v/3PH/50Hz or special order
Total Power(Full Loaded)	3-10KW	5-15KW
Min air compressor	1.0m3/min 3.0Mpa	1.6m3/min 3.0Mpa

Net dimension & Weight (LWH)
Blow Molding Machine	155×65×170cm	155×65×170cm
Pre-heater	180×70×140cm
Net Weight	0.88T	1.6T

Container
Container Volume	0.1-1.5L
Neck Diameter Range	8-60mm
Container Diameter	20-160mm
Container Height	10-360mm
