Specifications
Cylinder Screen printing machine1.Swingscreen printing machine
2.High accuracy & stability
3.Screen printing lot of material
Cylinder screen printing machine
Applications:
DSP series (Reversible press) Cylinder Screen Printing Machine is widely used in printing various semi-rigid materials, such as ceramic decal, cardboard,PVC,PP,PE,soft PCB, transfer paper and film switch etc.
Because the machine is suitable for many kinds of printing and controlled by simply operating, it wins much honor in the market.
Features:
|
Options:
Touch Screen Control panel
Unti-static&Dust eliminator
Pneumatic Locking of plate clamping(DSP1020 is Standard)
Front Pick-up Feeder
Double sheet checking
Rebound device for thick paper
Technical specifications
MODEL |
DSP720 |
DSP780 |
TD1020 |
Max.Paper Size: (mm) |
720×520 |
780×540 |
1020×740 |
Min.Paper Size: (mm) |
350×270 |
350×270 |
560×350 |
Max.Printing Area: (mm) |
720×500 |
780×520 |
1020×720 |
*Paper Thickness: (g/m2 ) |
90-350 |
90-350 |
120-350 |
Screen Frame Size: (mm) |
880×880 |
940×940 |
1280×1140 |
*Printing Speed: (p/h) |
1000--3600 |
1000—3300 |
1000—3000 |
Total Power: (kw) |
7.58 |
7.78 |
8.47 |
Total Weight: (kg) |
3500 |
3800 |
5500 |
Exterior Dimension: (mm) |
4350×1960×1270 |
4350×2020×1270 |
4500×2450×1320 |
