Help CenterPaper Bag Making Machine
Related Products
Specifications
Paper bag making machine1.To make shopping bags
2.Best cost-effective paper bag making solution
3.Stable and durabl
Paper bag making machine
Applications
Paper bag making machine is used to produce all kinds of shopping bags.
Bag forming machine
Technical specifications of bag forming machine:
Machine |
Paper bag forming machine |
Sheet width |
720-1020mm |
Sheet length |
320-600mm |
Bag length: |
320-600mm |
Substrate: |
Carton:157-250gsm Kraft paper: 120-250gsm |
Gluing system: |
Electronic gluing |
Bag width: |
200-330mm |
Production speed: |
40-60 pcs/min |
Machine weight: |
5 tons |
Total power: |
6.5kw |
Machine dimension: |
9980X1500X1700mm (LxWxH) |
Standard configurations:
¨ Auto feeder
¨ Front and side lays
¨ Folding section
¨ Folding M side section
¨ Gluing section
¨ Folding section
¨ Pressing section
¨ Bag forming section
¨ Bag transportation section
Position |
PB330 |
|
A |
MAX |
30 |
MIN |
10 |
|
B |
MAX |
120 |
MIN |
60 |
|
C |
MAX |
120 |
MIN |
60 |
|
D |
MAX |
1020 |
MIN |
720 |
|
E |
MAX |
600 |
MIN |
320 |
|
Bag bottom pasting machine
Machine |
Paper bag bottom pasting machine |
Bag bottom: |
70-200mm |
Bag length: |
300-700mm |
Bag width: |
130-450mm |
Speed: |
800-1200 pcs/hour |
Gluing system: |
Electronic gluing system |
Motor capacity: |
2kw |
Mache weight: |
800kg |
Machine dimension: |
4500X825X820mm (LxWxH) |
