GPS GSM Combo Antenna 5m High Quanlity Cable Gold Palte Connector

Name: GPS GSM Combo Antenna 5m High Quanlity Cable Gold Palte Connector
Brand: Yetnorson
Availability: InStock

FOB Price

US$ 1 - 5.9 / Piece

20 Pieces(Min. Order)

Port Shenzhen
Payment TermsT/T Money Gram Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	Yetnorson
Model Number	YNX-GSM+GPS-003

Packaging Details

1 set Combo Antenna/ PE bag , Bubble envelope,Carton packaging or as request

Product Description

Specifications

Combo Antenna
1.High Quality.
2.Low Price.
3.Factory
4.Customize

GPS GSM Combo Antenna 5m high quanlity cable Gold palte connector

Product Description

1. Product Technical Specifiction:

GPS Electrical Specification
Center Frequency (MHz)	1575.42MHZ±2MHZ
Bandwidth (MHz)	6MHZ
Gain (dBi)	29dB±3dB
Input Impendence (Ω)	50Ω
V.S.W.R	≤1.8
Consumption Electric	<10mA
Polarization Intensity	R.H.C.P
Supply Voltage	DC3.3~5.0V
The Sound Coefficient	≤1.7dB
Axial Ratio	3dB
Max Input Power (w)	50
Operating Temperature	-40°C~+85°C
Storing Temperature	-20°C~+85°C
Cable length (mm)	3000
Connector Type	SMA-Male
Radome Color	Black
Dimension-mm	Φ72 x 21
Weight (g)	140
Fixed Mode	Screw(M12*20)
GSM Electrical Specifications
Frequency Range (MHz)	806~960/1710~2170
Input Impendence (Ω)	50
V.S.W.R	≤1.7
Gain (dBi)	3.5
Polarization Type	Vertical
Radiation Direction	Omnidirectional
Max Input Power (w)	50
Operating Temperature	-40°C~+85°C
Storing Temperature	-20°C~+85°C
Cable length (mm)	3000(10 ft)
Connector Type	SMA-Male
Radome Color	Black
Dimension-mm	Φ72 x 21
Waterproof	100% waterproof

Our Services

2. Payment Way:

We accept Paypal, T/T, Western Union, L/C and MoneyGram.

3. Shipment:

1. The parts from us are sure to have quality warranty, and they are double tested before shipping.
2. The items can be sent within 7working day after the payment reaches us, except for mass process, we will confirm the delivery in advance.
3. We can send your order by UPS/DHL/TNT/EMS/FedEx. Please contact us directly and we will use your preferred ways.
4. Any import fees or charges are the buyer's responsibility. But we can help you reduce and avoid import taxes by declaring prices low, declaring the contents as "electronic accessories" or other items and shipping in simple packaging.

4. Refund & Replacement

1. We can guarantee the product quality within 3 months.
2. If parts cannot work, we will return payment or replacement to you.
3. Any items must be returned in their original condition to qualify for a refund or replacement.
4. The buyer is responsible for all the shipping cost incurred.

Quality is essential to both of us, we believe that High quality, Low price,Mutual benefit will be good basis of our cooperation.

Please contact us if you have any questions or other requirement.
