Help CenterActive Gps Gsm Antenna With Sma Connector RG174 Cable
Related Products
-
High Quality Gps Gsm Mimo Combo Antenna Gsm Gps for Vehicle Double Cable Double ConnectorUS$ 2 - 5.9MOQ: 30 Pieces -
New Antenna GPS+GSM Decorative Car Antenna With SMA ConnectorUS$ 2 - 5.9MOQ: 5 Pieces
-
High Quality GPS+GSM Car Antenna for Universal VehiclesUS$ 2 - 5.9MOQ: 5 Pieces
-
ISO9001:2008 29dBi Antenna GPS GSM Amplified Antenna Omni GPS GSM Combination Antenna With RG174 Cable 3MUS$ 1.5 - 3.5MOQ: 1 Chain
-
Hot Selling 28dBi Antenna Car Long Range Dipole Antenna External Car GPS/GSM Antenna With RG174 3MUS$ 1.5 - 3.5MOQ: 1 Chain
Specifications
active gps gsm antenna1.LNA gain
2.High quality competitive price
3.Long meter antenna
4.GSM GPS Combination antenna
Active gps gsm antenna with sma connector RG174 Cable
Application
1.For GPS system,passive antenna,made of Ceramic Microstrip Substrate
2. Compact Size, Light Weight, Low Profile, Easy to Assemble and Hide
3. The high gain LNA is made of low noise microwave components to ensure the sensibility of the system.
Antenna |
Center Frequency |
1575.42±1MHz/800/1800/1900/2100mhz |
Band Width |
CF±5MHz |
|
Polarization |
RHCP |
|
Gain |
3dBic(Zenith) |
|
V.S.W.R |
<1.5 |
|
Impendance |
50Ω |
|
Axial Ratio |
3dB(max) |
|
Dimension |
20*20*4mm |
|
LNA |
Gain |
26±2dB |
Noise Figure |
<1.3 |
|
Filter Insertion Loss |
<3dB |
|
Ex-band Attenuation |
12dB@CF+50MHz/16dB@CF-50MHz |
|
Supply Voltage |
2.2~5V DC |
|
Current Consumption |
10~26mA |
|
V.S.W.R |
<2.0 |
|
Mechanical |
Cable |
RG174 |
Connector |
SMA/MCX/FAKRA or others |
|
Radome Material |
ABS |
|
Mounting Method |
Magnet |
|
Environmental |
Operating Temperature |
-40°C~+85°C |
Relative Humidity |
Up to 95% |
|
Ingress Protection |
IP67 |
|
Vibration |
10 to 55Hz with 1.5mm amplitude 2hours |
|
Environmentally Friendly |
ROHS Compliant |
Refund & Replacement
1. We can guarantee the product quality within one years .
2. If parts cannot work, we will return payment or replacement to you.
3. Any items must be returned in their original condition to qualify for a refund or replacement.
4. The buyer is responsible for all the shipping cost incurred.
GSM GPS active antenna ,gsm gps active antenna ,gsm gps active antenna,gsm gps active antenna
Quality is essential to both of us, we believe that High quality, Low price,Mutual benefit will be good basis of our cooperation.!!!
gps+gsm antenna ,gsm antenna ,gps antenna ,gps+gsm antenna ,gps gsm antenna ,antenna
