C6x400 Household Used Mini Metal Lathe Machine

Name: C6x400 Household Used Mini Metal Lathe Machine
Brand: mini metal lathe machine
SKU: 115322437
Availability: InStock

US$ 700 - 800 MOQ: 10 Sets

Key Specifications

Condition:

New

Type:

Horizontal

CNC or Not:

Normal

Shanghai Zhong Jing Imp. & Exp. Corporation

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Horizontal

CNC or Not Normal

Automatic Grade Manual

Max. Swing Diameter 250mm

Place of Origin Shanghai, China

Brand Name mini metal lathe machine

Model Number C6x400

Voltage 110-230V

Power(W) 550W

Dimension(L*W*H) 1140x600x450mm

Weight 145kg

Certification CE

After-sales Service Provided Overseas service center available

Mini Metal Lathe Machine

Feature:

-Near silent running

- Integral splash guard

- Metric and Imperial thread cutting

- Full range of accessories available

- Converts to a multi-purpose machine with the milling attachme

- Medium capacity, high quality lathe suitable for workshop or school use

Specification:

Specification	C6
Swing over bed	250 mm
Distance between centers	400 mm
Hole through spindle	20 mm
Spindle taper	MT3
Tailstock taper	MT2
Cross slide travel	110 mm
Compound travel	75 mm
Range of threads Metric version	0.4-3.0 mm(12 thread pitches)
Imperial version	10-44 TPI(8 thread pitches)
Motor output power	550W
Spindle speed	125-2000 rpm+10% (6steps)
Overall dimension	1040600450mm
Packing size (LWH)	1070640580mm
Weight(Net&Gross)	125/160 kg
