Home > Manufacturing & Processing Machinery > Machine Tools > Lathe > CQ6125x400 Mini Lathe Machine

CQ6125x400 Mini Lathe Machine

Name: CQ6125x400 Mini Lathe Machine
Brand: mini lathe machine
SKU: 115321053
Availability: InStock

CQ6125x400 Mini Lathe Machine thumbnail-1

US$ 700 - 900 MOQ: 5 Sets

Key Specifications

Get Latest Price

Condition:

New

Type:

Turning Center

CNC or Not:

Normal

Contact Supplier Request Quote Chat Now

Shanghai Zhong Jing Imp. & Exp. Corporation

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Turning Center

CNC or Not Normal

Max. Swing Diameter 250mm

Place of Origin Jiangsu, China

Brand Name mini lathe machine

Model Number CQ6125

Voltage 220V

Power(W) 550W

Dimension(L*W*H) 1150x560x570mm

Weight 120kg

Certification CE

After-sales Service Provided Overseas service center available

Specifications

mini lathe machine
1.Supersonic frequency harden and precision ground bedway available on request

Product Description

CQ6125 Mini Lathe Machine

Feature:

1. Precision ground and supersonic frequency hardened bed ways.

2. With high accuracy and well wear-resisting

3. The spindle is supported with precision roller bearing

4. Safety magnetic switch or lock key switch

Specification:

Model	CQ6125
Max. swing over bed	250mm
Max. swing over cross slide	140mm
Distance between centers	400mm
Spindle bore	21mm
Taper of spindle bore	M.T.#3
Range of spindle speed	125-2000rpm
Range of longitudinal feeds	0.1-0.2mm/rev.
Range of metric threads	0.1-2.5mm
Range of inch threads	8-56TPI
Max. Size of tool shank	14 x 14mm
Taper of tailstock bore	M.T.#2
Power of motor	550W

Unitary packaging size and weight:

Type of lathes	Packing dimensions	Net weight	Gross weight
CQ6125 x 400	1075x625x1330mm	139kg	189kg
CQ6125 x 550	1185x625x1330mm	143kg	193kg
CQ6125 x 750	1385x625x1330mm	153kg	203kg

Asunder packaging size and weight:

Type of lathes	Packing dimensions	Net weight	Gross weight
CQ6125 x 400	1045x560x565mm	112kg	152kg
CQ6125 x 550	1155x560x565mm	116kg	156kg
CQ6125 x 750	1355x560x565mm	126kg	166kg
