Specifications
PVC Window Profile Making Line1.Used for window profile making .
2.Output:80-600kg/h.
3.Main machine :Extruder.
PVC Window Profile Making Line
The SJZ-series PVC window profile making line is used for PVC window decorative profile extruding . It can produce profile with different shapes and sizes of (width)300mm.
The whole production line can be purchased the SIEMENS PLC controly system and can realise the taotally automatic control.
It has the characters of low power consumption and high capacity, easy to operate and maintain.Alaso can runing24hours/day. We also offer one year quality guarantee which ensure the customers factory normal running.
The Whole lines include :
1.Hot and cool mixer machine unit .
2.Twin screw extruder machine .
3.PVC widnow profile mould .
4.Vacuum caliber moulding machine .
5.Haul-off and cutting machine .
6.Pile machine .
Type |
SJZ-55/110 |
SJZ-65/132 |
SJZ-80/156 |
SJZ-92/188 |
Screw Diameter(mm) |
55/110 |
65/132 |
80/156 |
92/188 |
Screw Quantity(mm) |
2 |
2 |
2 |
2 |
Direction of Screw Rotation |
Different direction, Outward direction |
|||
Screw Speed(rpm) |
1-30 |
1-34.7 |
1-36.9 |
1-32.9 |
Effective Screw Working Length(mm) |
1200 |
1440 |
1800 |
2500 |
Main Motor Power(kw) |
22 |
37 |
55 |
90 |
Barrel Heating Power(kw) |
18 |
24 |
36 |
86.8 |
Output(kg) |
80-140 |
250-300 |
320-450 |
500-600 |
Center Height(mm) |
|
1000 |
|
1200 |
Weight(kg) |
3500 |
4000 |
5000 |
10000 |
Dimension(mm) |
3620×1050×2157 |
4235×1520×2450 |
4750×1550×2460 |
6725×1550×2841 |
Model |
BXY-90 |
BXY-150 |
BXY-240 |
BXY-300 |
Extruder model |
SJSZ-50/105 |
SJSZ-65/132 |
SJSZ-65/132 |
SJSZ-80/156 |
Moulding table length |
3000mm |
4000mm |
6000mm |
9000mm |
Max boards width |
90mm |
150mm |
240mm |
300mm |
Hauling speed |
0-8m/min |
0-8m/min |
0-6m/min |
0-4m/min |
Total power |
55kw |
90kw |
110kw |
220kw |
