Specifications
PVC pipe machine1.Conical twin screw extruder
2.High output
3.Low power consumption
4.SGS,CE,ISO9001:2008
Top Quality Plastic PVC Conduit Pipe Making Machine
PVC Pipe extrusion line
PVC Pipe extrusion machine
PVC tube machine upvc water
Application of the Pipes Produced:
They are applied to agricultural and construction water supply and drainage, overhead or underground wire and cable.
Features of the Machine:
The conical (parallel) double-screw extruder and tractor adopts AC frequency control or British Euro DC speed regulator.
Vacuum pump and tractor adopts high-quality products. Tractors can be divided into up and down pedrail, three-claw, four-claw, six-claw, etc. in terms of thickness and diameter of the pipe.
The cutter has two modes of cutting such as blade and planet type. Additionally, metering device is equipped. The property of the production line is reliable and the output is high. In accordance with different requirements of the clients, the company will equip the extrusion line with specific devices to form pipe production lines of inner-wall spiral pipes, inner hollow wall pipes and inner layer foaming pipes.
Main Technical Parameters of the Machine:
Model |
Pipe Diameter(mm) |
Extruder Model |
Line Speed (m/min) |
Output (kg/h) |
Power (kw) |
Dimension (L×W×H) |
SSG-63P |
Φ16-63 |
SJSZ-51/105 |
1-12 |
120 |
65 |
30×1.8×2 |
SSG-160P |
Φ75-160 |
SJSZ-65/132 |
0.5-5 |
260 |
105 |
36×2×2 |
SSG-250P |
Φ90-250 |
SJSZ-80/156 |
1-3.6 |
400 |
145 |
37×2×2 |
SSG-400P |
Φ200-400 |
SJSZ-92/188 |
0.2-2 |
600 |
210 |
42×2.5×2.5 |
SSG-630P |
Φ400-630 |
SJSZ-92/188 |
0.08-0.8 |
700 |
245 |
48×2.5×2.5 |
The parameter may change without previous notice.
Equipment List of the Machine:
Double screw extruder→die and mould →vacuum calibration water tank → tractor → cutting machine and stacker
