Help CenterNew Product!! Metal Lathe Cutting Tools
Related Products
metal lathe cutting tools
1. H6236 metal lathe cutting tools specification
| metal lathe cutting tools | H6236 |
| Max. swing over bed | 360mm |
| max. swing over cross slide | 140mm |
| Collet | optional |
| Max. truning length | 250mm |
| chuck | 6" manual chuck |
| x axis | 270mm |
| z axis | 250mm |
| Guideway | Taiwan Hiwin Linear guideways |
| Spindle speed | 2500 rpm |
| Spindle nose | A2-5 |
| Thru-hole dia of spindle | 38mm |
| Fast moving speed | x:15m/min z:20m/min |
| Spindle motor | 4kw |
| x/z motor torque | 4/4 Nm |
| Tool bar section | 16*16mm |
| Tools | 4 tools gany type post |
| x/z position accuracy | 0.016/0.02 mm |
| x/z repeatability | 0.006/0.006mm |
| machine dimension | 1530*1120*1550mm |
| N.W. | 1500KG |
2.Standard accessories for this metal lathe cutting tools
6" manual chuck
4 tools gang type post
3. Optional accessories for this small metal lathe cutting tools
collet,
4 tool electric tool post.
4.Warranty for all of our machine tools
1. engineers are available to do oversea machinery service. In some countries, we have oversea
agent doing after-sale service in time and professionally.
2.24 hours heart to heart service on-line or mobile.
3. training in our factory and on-line are free of cost.
4. warranty is 12 months, small broken parts are free of cost to replace, spare parts are delivered
with machine for customer convenience.
5.We offer best agent price and distributer price.
5.Customer and delivery
accept ODM, OEM,
accept FOB, CFR, CIF, EXW price,
T/T 30% as deposit and the balance before machine tools leave our factory.
normal products with standard configuration manufacturing time is 7-15 working days.
