linear guide cnc lathe machine speciation
1. H36 linear guide cnc lathe machine speciation
linear guide cnc lathe machine |
Unit |
H36 |
Max. swing over bed |
mm |
Φ360 |
Max. sing over cross slide |
mm |
Φ110 |
Max. processing length |
mm |
250 |
Chuck |
inch |
6″ optional |
X axis travel |
mm |
340 |
Z axis travel |
mm |
250 |
Spindle unit speed |
rpm |
2500 /4000 |
Spindle nose |
|
A2-5 |
Thro-hole diameter of spindle |
mm |
Φ48 |
Spindle drawing bar diamter |
mm |
Φ38 |
Rapid feed speed |
m/min |
X:15 Z:15 |
Spindle motor power |
kw |
4 |
X/Z motor power |
kw |
1/1.5 |
X/Z motor torque |
N.m |
4/4 |
Tool bar section |
mm |
20×20 |
Optional |
|
4-station electric turret |
X/Z position accuracy |
mm |
0.016/0.02 |
X/Z repeatability |
mm |
0.006/0.006 |
Machine dimension (L*W*H) |
mm |
2000×1400×1580 |
N.W. |
KG |
1500 |
2. H36 linear guide cnc lathe machine speciation
higher accuracy Taiwan HWIN linear guideway
higher speed 4000rpm spindle unite
higher rigidity cast iron
integrated automatic lubrication system
3. H36 linear guide cnc lathe machine speciation
This CNC lathe is suitable top process various small and middle-size shaft and plate work piece,
could turn various threads, circle arc, circle cone,inside and outside surface of revolved body, widely
used in sanitary, valve, electric appliance, instrument, automobile, motor-circle, bearing and so on.
3. H36 linear guide cnc lathe machine speciation
GSK980TDC or Siemens 808d NC system
invertor motor 4kw
4 station gang type tool post
spring collet
automatic integrated lubrication system
coolant system
lighten system
4. H36 linear guide cnc lathe machine speciation
KND 1000Ti, Fanuc 0I MATE TD NC system
servo motor 3.7/5.5 kw
inverter 5.5 kw
4 station electric turret
6″Non-through hole hydraulic chuck
6″through hole hydraulic chuck
6″Non-through hole hydraulic chuck (Taiwan)
6″through hole hydraulic chuck(Taiwan)
Before send your inquiry, please offer the following info.
1. list work piece all outer diameters and inner diameters
2. work piece max. length
3. work piece material and usage
4. pictures and drawings are best to send to us
Please click send now and learn more about our products.
