taian gang tool metal spinning lathe with gang post
1. H6240 taian gang tool metal spinning lathe with gang post
| taian gang tool metal spinning lathe with gang post | H6240 |
| Max. swing over bed | 400mm |
| max. swing over cross slide | 140mm |
| Collet | optional |
| Max. truning length | 250mm |
| chuck | 6" manual chuck |
| x axis | 360mm |
| z axis | 380mm |
| Guideway | Taiwan Hiwin Linear guideways |
| Spindle speed | 4000 rpm |
| Spindle nose | A2-5 |
| Thru-hole dia of spindle | 38mm |
| Fast moving speed | x:15m/min z:20m/min |
| Spindle motor | 5.5kw |
| x/z motor torque | 6/6 Nm |
| Tool bar section | 20*20mm |
| Tools | 4 tools gany type post |
| x/z position accuracy | 0.016/0.02 mm |
| x/z repeatability | 0.006/0.006mm |
| machine dimension | 2000*1300*1600mm |
| N.W. | 2200KG |
H6240 taian gang tool metal spinning lathe with gang post
GSK980TDC or Siemens 808d NC system
invertor motor 5.5kw
4 station gang type tool post
spring collet
automatic integrated lubrication system
coolant system
lighten system
H6240 taian gang tool metal spinning lathe with gang post
KND 1000Ti, Fanuc 0I MATE TD NC system
servo motor 5.5/7.5 kw
inverter 7.5 kw
4 station electric turret
6″Non-through hole hydraulic chuck
6″through hole hydraulic chuck
6″Non-through hole hydraulic chuck (Taiwan)
6″through hole hydraulic chuck(Taiwan)
Our Services1.Engineers are available to do oversea machinery service. In some countries, we have oversea
agent doing after-sale service in time and professionally.
2.24 hours heart to heart service on-line or mobile.
3.Training in our factory and on-line are free of cost.
4.Warranty is 12 months, small broken parts are free of cost to replace, spare parts are delivered
with machine for customer convenience.
5.Best agent price and distributer price are offered.
Before order, please kindly inform the following,
1.Work piece max. length, max. O.D., material etc
2.Work piece drawings
3. Need cutters, clamping set or not
4.Customer service
Click " send " now and learn more about our products.
Please talk with us on alibaba TM right now.
