cnc lathe 1 meter
1.Factory covers 120,000 square meters
2.Our casting workshop adopts lost foam to guarantee the size and precision of casting parts.
3.All the parts are performed heat treatment, natural failure, vibrating stress relief(VSR) to relieve
internal stresses.
4.All the guide surface are performed quenching, hardness is HRC45-52 degrees.
5.We implement assembly line,and the assemble workshop includes feed box team,gear box team,
worktable team,hydraulic unit team,scrabbing team,drilling hole team,power distrubition team,
daubing and painting team, test team and after-sale service team.
6.ERP infomation management makes our production and management more and more
standardization, networked and refinement.
Specification CK6150 cnc lathe 1 meter
| benchtop cnc lathe | CK6150 | |
| Capability | Max. swing dia. over bed | 500mm |
| Max. swing dia. over cross slide | 250mm | |
| Max. cutting dia. | 500mm | |
| Max. processing length | 850mm/1500mm | |
| Spindle | spindle bore | 130mm |
| Spindle taper | MT6# | |
| Spindle speed | 1800rpm | |
| Spindle nose | A2-8/11 | |
| Main motor power | 7.5Kw | |
| X/Z axis | X/Z travel | 300/900 1600mm |
| X/Z mini setting unite | 0.001mm | |
| X/Z motor torque | 4/6N.m | |
| X/Z repeatability | 0.005/0.005mm | |
| X/Z position accuracy | 0.006/0.006 m/min | |
| Tailstock | Tailstock sleeve dia. | 75mm |
| Tailstock sleeve travel | 200mm | |
| Tailstock taper | MT5# | |
| Tool holder | Type | 4-position electric type |
| Tool bar size | 25*25mm | |
| Tool holder repeatability | 0.004 | |
| Dimension | 2950*1520*1750mm | |
| Net weight | 2850kg | |
Standard Accessories CK6150 benchtop cnc lathe
plete coolant system for ready use
plete lubrication system for ready use
3. advanced LED work light
4. 10" three jaw manual chuck
5. 4 position electric tool post
6. manual tailstock
7.MPG
8. tool box and tools
CK6150 benchtop cnc lathe
1. automatic feeding device for long bar work piece
2. chip conveyor
3. 10" hydraulic chuck, hydraulic station, rotaty cylinder
4. steady rest
5. fellow rest
6. 6 position electrical tool post
Before order, please kindly inform the following,
1.Work piece max. length, max. O.D., material etc
2.Work piece drawings
3. Need cutters, clamping set or not
4.Customer service
