TCK6340 45 Degrees Slant Bed Cnc Late

TCK6340 45 Degrees Slant Bed Cnc Late thumbnail-1
TCK6340 45 Degrees Slant Bed Cnc Late thumbnail-2
TCK6340 45 Degrees Slant Bed Cnc Late thumbnail-3
TCK6340 45 Degrees Slant Bed Cnc Late thumbnail-4
TCK6340 45 Degrees Slant Bed Cnc Late thumbnail-5
TCK6340 45 Degrees Slant Bed Cnc Late photo-1
TCK6340 45 Degrees Slant Bed Cnc Late photo-2
TCK6340 45 Degrees Slant Bed Cnc Late photo-3
TCK6340 45 Degrees Slant Bed Cnc Late photo-4
TCK6340 45 Degrees Slant Bed Cnc Late photo-5
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
PULUTE
Contact Supplier Request Quote Chat Now
Shandong Pulute Machine Tool Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shandong, China
Brand Name PULUTE
Model Number TCK6340
Voltage 380V
Rated Power 5.5KW
Dimension(L*W*H) 1800*1750*1700MM
Weight 1800KG
Certification CE, ISO9001, ISO14001
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

cnc late

Company Information

TCK6340 45 degrees slant bed cnc late



Product Description

 TCK6340  slant bed  cnc late specification

slant bed cnc late
TCK6340
Max. swing over bed 400mm
max. swing over cross slide 140mm
x axis travel 400mm
z axis travel
 500mm
Guideway Taiwan Hiwin Linear guideways
Spindle speed 1500rpm/4500rpm
Thru-hole dia of spindle 48mm
Fast moving speed 20m/min
Spindle motor 5.5kw
x/z motor torque 7/7 Nm
Tool bar section 25*25mm
Tools 8 tool turret
x/z position accuracy 0.005 mm
x/z repeatability 0.0025mm
machine dimension 1800*1340*1410mm

 TCK6340 45 degrees slant bed cnc lateTCK6340 45 degrees slant bed cnc late



Standard accessories

standard accessories slant bed cnc late

6" hydraulic chuck

8 tools turret

spindle unite 4500 rpm

Taiwan Hiwin linear guideway

6" hollowed oil cylinder

Packaging & Shipping

packing and shipping of cnc late

TCK6340 45 degrees slant bed cnc late



TCK6340 45 degrees slant bed cnc late

Our Services

1.Engineers are available to do oversea machinery service. In some countries, we have oversea

agent   doing after-sale service in time and professionally.

2.24 hours heart to heart service on-line or mobile.

3.Training in our factory and on-line are free of cost.

4.Warranty is 12 months, small broken parts are free of cost to replace, spare parts are delivered

with machine for customer convenience.

5.Best agent price and distributer price are offered.


FAQ

 Before order, please kindly inform the following,

1.Work piece max. length, max. O.D., material etc

2.Work piece drawings

3. Need cutters, clamping set or not

4.Customer service
