cjk6132 cnc lathe for seal
1. cjk6132 cnc lathe for seal specification
| cjk6132 cnc lathe for seal | CJK6132 |
| max. swing over bed | 320 mm |
| max. swing over cross slide | 90 mm |
| max. processing length | 400 mm |
| spindle hole | 48 mm |
| drawing pipe dia. | 41 mm |
| spindle speed | 150-3000rpm |
| X/Z fast feeding speed | 8/10 m/min |
| spindle motor | 4 kw |
| tool post |
4 station electric tool post |
| tailstock travel |
100 mm |
| n.w. | 1220 kg |
| machine dimension | 1750*1200*1570 mm |
cjk6132 cnc lathe for seal
manual chuck
4 piece gang type tool post
4 station electric tool carrier
pneumatic collet
manual tailstock
complete coolant system
complete lubrication system
work light
tool box and lots of tools like wrenches, machine feet, screw drivers, allen wrench etc.
Optional accessories
cjk6132 cnc lathe for seal
KND100Ti or Fanuc 0I mate-TD
servo motor 3.7/5.5 kw
inverter motor 5.5 kw
160mm manual chuck
160mm domestic thu-hole hydraulic chuck
160mm domestic none thru-hole hydraulic chuck
160mm domestic thu-hole hydraulic chuck (Taiwan brand)
160mm domestic none thru-hole hydraulic chuck(Taiwan brand)
1.Engineers are available to do oversea machinery service. In some countries, we have oversea
agent doing after-sale service in time and professionally.
2.24 hours heart to heart service on-line or mobile.
3.Training in our factory and on-line are free of cost.
4.Warranty is 12 months, small broken parts are free of cost to replace, spare parts are delivered
with machine for customer convenience.
5.Best agent price and distributer price are offered.
1.Factory covers 120,000 square meters including casting,machinning,assemble 4 workshops, above
70 intermediate and senior technical personel.
2.Our casting workshop adopts lost foam to guarantee the size and precision of casting parts.
3.All the parts are performed heat treatment, natural failure, vibrating stress relief(VSR) to relieve
internal stresses.
4.All the guide surface are performed quenching, hardness is HRC45-52 degrees.
5.We implement assembly line,and the assemble workshop includes feed box team,gear box team,
worktable team,hydraulic unit team,scrabbing team,drilling hole team,power distrubition team,daubing and
painting team, test team and after-sale service team.
6.ERP infomation management makes our production and management more and more
standardization, networked and refinement.
Before order, please kindly inform the following
1.Work piece max. length, max. O.D., material etc
2.Work piece drawings
3. Need cutters, clamping set or not
4.Custom service
