CK6140 Cnc Lathe With Auto Bar Feeder

Name: CK6140 Cnc Lathe With Auto Bar Feeder
Brand: Pulute
SKU: 115200723
Availability: InStock

US$ 10540.00 - 10540.00 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Horizontal

CNC or Not:

CNC

Shandong Pulute Machine Tool Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Shanghai Ningbo Taijin

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Horizontal

CNC or Not CNC

Automatic Grade Automatic

Max. Swing Diameter 400mm

Place of Origin Shandong, China

Brand Name Pulute

Model Number CK6140

Voltage 380V

Power(W) 5.5 kw

Dimension(L*W*H) 2200*1100*1620mm

Weight 1800kg

Certification CE, ISO

After-sales Service Provided Engineers available to service machinery overseas

cnc lathe with auto bar feeder

1. bar requirement

bar diameter 3-45mm, max. bar length 2500 mm, with quite higher efficiency than normal CNC lathe.

2. cnc lathe with auto bar feeder CK6140 configuration

8" thru-hole hydraulic chuck or hydraulic collet, meet auto feeding requirement and improve working efficiency.
4 position electric turret, orientates and changes cutting tools automatically ( cheap price 4 position gang type tool post optional)
hydraulic tail stock, is optional.
removing auto feeder, CNC lathe could be used normal CNC lathe too.
This type auto feeder CNC lathe has been exported too lots of countries. All of customers feed back very well.

3. cnc lathe with auto bar feeder CK6140 advantages

wider guide width to 300mm, improve bed rigidity and stability for long servicing time
advanced spindle structure enable inverter stepless speed up to 2000RPM
45 degrees hardness, high frequency quenched guide way
full cover, good water proof advantage, good dust and chip proof advantage
complete set coolant system
automatic integrated lubrication system
advanced LED lighten system
three color warning light
complete files like user manual, main motor driver manual, video, CD etc

4. cnc lathe with auto bar feeder CK6140 specification

cnc lathe with auto bar feeder	specification
max. swing over bed	400mm
Max. swing over cross slide	250mm
Max. processing length	600mm
Spindle bore	45mm
Spindle speed	2000rpm
Spindle nose	A2-6
Spindle motor power	5.5kw
X/Z axis position accuracy	0.01/0.015mm
X/Z axis repeatability	0.012/0.013mm
X/Z axis motor torque	5.5/7.5 N.m
X/Z axis motor power	1/1.5kw
X/Z axis rapid feeding speed	8/10 m/min
Tool bar section	20*20mm
Tail stock sleeve dia	60mm
Tail stock sleeve travel	100mm
Tail stock taper	MT4#
N.W.	1800kg
Machine dimension (LWH)	220011001620mm
