Ck0640 Back Auto Feeder Cnc Lathe

Ck0640 Back Auto Feeder Cnc Lathe thumbnail-1
Ck0640 Back Auto Feeder Cnc Lathe thumbnail-2
Ck0640 Back Auto Feeder Cnc Lathe thumbnail-3
Ck0640 Back Auto Feeder Cnc Lathe thumbnail-4
Ck0640 Back Auto Feeder Cnc Lathe thumbnail-5
Ck0640 Back Auto Feeder Cnc Lathe thumbnail-6
Ck0640 Back Auto Feeder Cnc Lathe photo-1
Ck0640 Back Auto Feeder Cnc Lathe photo-2
Ck0640 Back Auto Feeder Cnc Lathe photo-3
Ck0640 Back Auto Feeder Cnc Lathe photo-4
Ck0640 Back Auto Feeder Cnc Lathe photo-5
Ck0640 Back Auto Feeder Cnc Lathe photo-6
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Horizontal
CNC or Not:
CNC
Contact Supplier Request Quote Chat Now
Shandong Pulute Machine Tool Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai Ningbo Taijin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Horizontal
CNC or Not CNC
Automatic Grade Automatic
Max. Swing Diameter 400mm
Place of Origin Shandong, China
Brand Name Pulute
Model Number CK6140
Voltage 380V
Power(W) 5.5 kw
Dimension(L*W*H) 2200*1100*1620mm
Weight 1800kg
Certification CE, ISO
After-sales Service Provided Engineers available to service machinery overseas

back auto feeder cnc lathe

ck0640 back auto feeder cnc lathe





1.    ck0640 back auto feeder cnc lathe  advantages

  •   wider guide width to 300mm, improve bed rigidity and stability for long  servicing time
  •  advanced spindle structure enable inverter stepless speed up to 2000RPM
  • 45  degrees hardness, high frequency quenched guide way
  • full cover, good water proof advantage, good dust and chip proof advantage
  • complete set coolant system
  • automatic integrated lubrication system
  • advanced LED lighten system
  • three color warning light
  • complete files like user manual, main motor driver manual, video, CD etc

2.  ck0640  back auto feeder cnc lathe specification

  back auto feeder cnc lathe

specification

max. swing over bed

400mm

Max. swing over cross slide

250mm

Max. processing length

600mm

Spindle bore

45mm

Spindle speed

2000rpm

Spindle nose

A2-6

Spindle motor power

5.5kw

X/Z axis position accuracy

0.01/0.015mm

X/Z  axis repeatability

0.012/0.013mm

X/Z axis motor torque

5.5/7.5 N.m

X/Z axis motor power

1/1.5kw

X/Z axis rapid feeding speed

8/10 m/min

Tool bar section

20*20mm

Tail stock sleeve dia

60mm

Tail stock sleeve travel

100mm

Tail stock taper

MT4#

N.W.

1800kg

Machine dimension (L*W*H)

2200*1100*1620mm



3.more pictures of  ck0640 back auto feeder cnc lathe

 ck0640 back auto feeder cnc lathe

ck0640 back auto feeder cnc lathe

ck0640 back auto feeder cnc lathe

4.Delivery of CK6140 back auto feeder cnc lathe

ck0640 back auto feeder cnc lathe


5. Training could be offered.


ck0640 back auto feeder cnc lathe
