4 Axis 3kg Load 400mm Wingspan Horizonal Joint Scara Robot
Features:
SC series is SCARA robot (Selective Compliance Assembly Robot Arm).
SCARA robot has 3 rotary joints, the axis are parallel. And the 4th axis is prismatic joint, can finish the vertical movement, this robot has portable structure, fast response, especially suit for plane positioning, vertical assembly.
* Four axis multi-joint bobot
* Applied to electronics assemble ,handling
* Highly cost performance
* Highly efficiency ,saving cost
* Space linear interpolation motion
Specifications:
Model |
SC3-400 |
||
Axis |
4 |
||
Max. Load (KG) |
3 |
||
Repetitive. Accuracy.( mm) |
+/-0.05 |
||
Motion Angle |
1axis
|
+/-115° |
|
2axis |
+/-154° |
||
Z axis |
0-160mm |
||
U axis |
+/-360° |
||
|
|
||
|
|
||
Max. Moving speed |
1axis
|
225°/s |
|
2axis |
360°/s |
||
Z axis |
0.8m/s |
||
U axis |
2250°/s |
||
|
|
||
|
|
||
Permitted Inertia (GD^2/4) |
1axis
|
0.15kg*m^2 |
|
2axis |
0.1kg*m^2 |
||
|
U axis
|
0.09kg*m^2 |
||
Weight |
24kg |
||
Environment |
Temp. |
0-45° |
|
Humidity |
20-80%RH |
||
Rated Power |
1.5KW |
||
Drawings:
Meitoo Automation Co., Limited(Meitoo for short) is a high-tech enterprise Which focuses on robotic & automation technologies research ,manufacturing and marketing. Through continuous independent innovation, Meitoo has contributed to the automation of machine industry and offered innovative, energy efficient, reliable robots, applications and services to meet user's requirements for higher accuracy, performance and efficiency.
Meitoo provides a wide range of products, including robots, planetary reducer for robots, CNC controllers, servo drives & motors, offers a complete industry solution for users worldwide. Our leading product is robots that are well accepted by end users for their high performance and reliability with their most favorable prices. The products are Widely using for plastic, auto, electronics, medicine and food industry.
