CNC Milling machine controller, support OEM with plc function

CNC Milling machine controller, support OEM with plc function

Application:

3-5 axis CNC precision milling machine, CNC boring machine, CNC drilling machine etc. heavy special purpose machine

Product Feature:

1. Five axes of X, Z, Y, 4th, 5th control, any three axes linkage movement, the axial name and the axial type of y 4th, 5th can be defined.

2. 2 ms interpolation cycle and the control precision of 1μm,0.1μm could be selected.

3. Maximum speed: 60 m/min (When it is 0.1μm, the maximum speed is 24 m/min)

4.Multiple functions, it can realize the drilling/boring, roughing of round groove/rectangle groove, finishing of full circle/rectangle, continuous drilling of straight line/rectangle/arc etc.

5. Adaptive servo spindle can realize continuous positioning, rigid tapping spindle, rigid threads processing

6. The built-in PLC program, the current running PLC program can be selected. Memory storage: 40M

7. Support the statement type of macro programming, support with parameters of macro program calls

8. Support the metric/imperial programming, has the ability of automatic knife, automatic chamfering, cutting tool life management function

9. Support Chinese, English language, according to the parameter selection

10.USB interface, support USB file processing, system configuration and software upgrades

11. DNC in high speed, realize part program real-time transmission processing.

12. Analog voltage output 0V~10V in two channels and support two-spindle control.

13. One channel for handwheel (MPG), supporting external MPG, Common input in 40 points/32 points output
