Heavy Loading Motorized Rotation Stage (diameter 300mm)
1. Specification:
Item Number |
01DX300 |
Angle Range |
360° |
Dimension |
diameter 60mm |
Worm Gear Ratio |
288:1 |
Drive Mechanism |
Worm Gear |
Guide |
Bearing |
Stepper Motor(1.8°) |
SST57D3301 |
Material |
Aluminum |
Surface Treatment |
Black- Anodized |
Loading |
62kg |
Weight |
12kg |
Resolution |
0.01°non-driver 0.005°20 MS driver |
Speed |
25°/sec |
Repeatability |
0.005° |
Accuracy |
0.01° |
Run Out of Top |
15μm |
Backlash |
0.005° |
Eccentricity |
5μm |
Degree of Parallelization |
80μm |
2. Feature:
1) Regular stage set with stepper motor and RS232 interface, could connect with motion controller easily
2) High precision Worm gear design for high accuracy, loading and long working time.
3) Forward and reverse rotate are possible
4)The stage could use in vertical and assemble with other stages
5) 300mm diameter dimension and with rough dia 200mm through hole for add rotating encode possible
6)The regular stage without limit switch and home position, but can add according to requirements
3. Drawing:
4. Product:
If you have any questions, pls feel free to contact me!
